John Deere 870G
Browse All John Deere or Motor Grader Models
Contents:
Dimensions
| Overall Length | 29.17 ft in (8890 mm) |
| Width Over Tires | 8.17 ft in (2490 mm) |
| Wheelbase | 6160 ft in (1877568 mm) |
| Tandem Axle Wheelbase | 1540 ft in (469392 mm) |
| Blade Base | 2530 ft in (771144 mm) |
| Height To Top Of Isomount Cab | 10.44 ft in (3180 mm) |
Engine
| Number Of Cylinders | 6 |
| Net Power Gear 4-6 | 245.5 hp (183 kw) |
| Engine Make | 2240 |
| Engine Model | PowerTech PSS 9.0L |
| Net Power Gear 1-2 | 214.6 hp (160 kw) |
| Net Power Gear 5-6 | 260.2 hp (194 kw) |
| Torque Rise | 62 % |
| Net Power Gears 7-8 | 275 hp (205 kw) |
| Net Torque Gears 1-2 | 1053.3 lb ft (1428 Nm) |
| Displacement | 549.3 cu in (9 L) |
Operational
| Hydraulic System Fluid Capacity | 16 gal (60.5 L) |
| Oil System Fluid Capacity | 7.6 gal (28.4 L) |
| Fuel Capacity | 110.1 gal (416.5 L) |
| Cooling System Fluid Capacity | 14.6 gal (55 L) |
| Transmission Fluid Capacity | 6.3 gal (23.5 L) |
Transmission
| Number Of Gears - Forward | 8 |
| Number Of Gears - Reverse | 8 |
| Max Speed - Forward | 28 mph (45 km/h) |
| Max Speed - Reverse | 28 mph (45 km/h) |
Moldboard
| Moldboard Height | 27.1 in (686 mm) |
| Moldboard Thickness | 1 in (25 mm) |
Hydraulic System
| Pump Type | Closed-center, pressure-compensated load-sensing (PCLS), variable-displacement piston pump |
| Pump Flow | 57.6 gal/min (218 L/min) |
| Relief Valve Pressure | 2750.1 psi (18961 kPa) |
