Caterpillar PS180
Browse All Caterpillar or Pneumatic Roller Models
Contents:
Dimensions
| Overall Length | 13.59 in (4140 mm) |
| Overall Width | 6.09 ft in (1854 mm) |
| Height To Top Of Rops | 8.67 ft in (2641 mm) |
| Wheelbase | 11.01 ft in (3353 mm) |
| Ground Clearance | _ - (276 mm) |
Engine
| Engine Make | 2351 |
| Engine Model | 4.236 |
| Gross Power | 76.5 hp (57 kw) |
| Displacement | 238 cu in (3.9 L) |
Operational
| Fuel Capacity | 33.9 gal (128 L) |
| Engine Oil Capacity | 1.3 gal (4.7 L) |
| Water Spray Tank Fluid Capacity | 100.4 gal (380 L) |
| Max Speed | 24 mph (38.6 km/h) |
Weights
| Operating Weight - Standard | 11009.9 lb (4994 kg) |
| Operating Weight - Max Ballast | 37269.2 lb (16905 kg) |
| Average Weight Per Wheel - Max Ballast | 3999.2 lb (1814 kg) |
Tires
| Number Of Tires - Front | 5 |
| Number Of Tires - Rear | 4 |
| Standard Tire Size | 7.5x15 10ply |
