Euclid R85B
Browse All Euclid or Rock Truck Models
Contents:
Dimensions
| Overall Length | 33.67 ft in (10262.62 mm) |
| Overall Width | 17.83 ft in (5434.59 mm) |
| Overall Height | 16.75 ft in (5105.4 mm) |
| Wheelbase | 15.17 ft in (4623.82 mm) |
| Ground Clearance | 2 ft in (609.6 mm) |
| Dump Height | 31.67 ft in (9653.02 mm) |
| Dump Ground Clearance | 2.5 ft in (762 mm) |
Dump
| Lower Time | 17 sec |
| Load Capacity - Heaped | 67.1 yd3 (51.31 m3) |
| Load Capacity - Struck | 46.6 yd3 (35.63 m3) |
| Rated Payload | 188054.3 lb (85300 kg) |
| Raise Time | 13 sec |
Engine
| Number Of Cylinders | 12 |
| Engine Make | 2347 |
| Engine Model | KT38-C |
| Net Power | 865 hp (645.1 kw) |
| Gross Power | 925 hp (689.8 kw) |
| Power Measured @ | 2100 rpm |
| Max Torque | 3020 lb ft (4094.6 Nm) |
| Displacement | 2300 cu in (37.7 L) |
| Aspiration | Turbocharged |
| Torque Measured @ | 1300 rpm |
Operational
| Fuel Capacity | 265 gal (1003.2 L) |
| Cooling System Fluid Capacity | 71 gal (268.8 L) |
| Engine Oil Capacity | 37 gal (140.1 L) |
| Diff And Final Drive Fluid Capacity | 39 gal (147.7 L) |
| Steering System Fluid Capacity | 30 gal (113.6 L) |
| Brake/Hoist System Fluid Capacity | 74 gal (280.2 L) |
| Hydraulic System Fluid Capacity | 104 gal (393.7 L) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 75 amps |
| Tire Size | 24.00-49(48)E-3 |
Transmission
| Transmission Type | Allison DP-8963 Planetary |
| Number Of Gears - Forward | 6 |
| Number Of Gears - Reverse | 1 |
| Max Speed | 33.6 mph (54.1 km/h) |
Weights
| Empty Weight | 132000 lb (59874.2 kg) |
| Loaded Weight | 315300 lb (143017.7 kg) |
| Weight Distribution Front - Loaded | 33 % |
| Weight Distribution Rear - Loaded | 67 % |
