Hitachi EH600
Browse All Hitachi or Rock Truck Models
Contents:
Dimensions
| Overall Length | 26.38 ft in (8040 mm) |
| Overall Width | 12.24 ft in (3730 mm) |
| Overall Height | 11.82 ft in (3600 mm) |
| Wheelbase | 11.98 ft in (3650 mm) |
| Ground Clearance | 1.48 ft in (450 mm) |
| Dump Height | 25.37 ft in (7730 mm) |
| Dump Ground Clearance | 1.51 ft in (460 mm) |
Dump
| Dump Angle | 55 degrees |
| Load Capacity - Struck | 19.11 yd3 (14.6 m3) |
| Load Capacity - Heaped | 27.5 yd3 (21 m3) |
| Rated Payload | 64000 lb (29029.92 kg) |
| Lower Time | 12 sec |
| Raise Time | 12 sec |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2347 |
| Engine Model | N14-C400 |
| Gross Power | 400 hp (298 kw) |
| Net Power | 384 hp (286 kw) |
| Power Measured @ | 2100 rpm |
| Aspiration | Turbocharged/Aftercooled |
| Displacement | 855 cu in (14 L) |
Operational
| Fuel Capacity | 145 gal (550 L) |
| Cooling System Fluid Capacity | 18.5 gal (70 L) |
| Engine Oil Capacity | 9 gal (34 L) |
| Hydraulic System Fluid Capacity | 29 gal (110 L) |
| Operating Voltage | 24 V |
| Tire Size | Michelin 18.00R25 E4 |
Transmission
| Transmission Type | Allison CLBT 754. Automatic planetary type transmission with built in retarder and 2nd gear start |
| Number Of Gears - Forward | 5 |
| Number Of Gears - Reverse | 1 |
| Max Speed | 37.1 mph (60 km/h) |
Weights
| Empty Weight | 52450 lb (23790 kg) |
| Loaded Weight | 125467 lb (56911 kg) |
| Weight Distribution Front - Empty | 50 % |
| Weight Distribution Rear - Empty | 50 % |
| Weight Distribution Front - Loaded | 32 % |
| Weight Distribution Rear - Loaded | 68 % |
