Terex GS3384RT
Browse All Terex or Scissor Lift Models
Contents:
Dimensions
| Overall Length | 12.93 in (3940 mm) |
| Wheelbase | 9.32 ft in (2840 mm) |
| Overall Width | 6.99 ft in (2130 mm) |
| Height W/ Rails | 8.8 ft in (2680 mm) |
| Ground Clearance | 13 in (330 mm) |
| Gradeability | 50 % |
| Turning Radius - Outside | 19.49 ft in (5940 mm) |
| Turning Radius - Inside | 10.14 ft in (3090 mm) |
| Height W/O Rails | 6.57 ft in (2000 mm) |
Platform
| Max Platform Height | 33.01 ft in (10060 mm) |
| Deck Extension | 59.85 in (1520 mm) |
| Max Working Height | 39.57 ft in (12060 mm) |
| Platform Inner Length | 156.7 in (3980 mm) |
| Platform Inner Width | 72.05 in (1830 mm) |
| Max Platform Weight Capacity | 2500.05 lb (1134 kg) |
| Lower Time | 29 sec |
| Lift Time | 45 sec |
Engine
| Engine Make | 2380 |
| Engine Model | DSG-423 |
| Gross Power | 75 hp (56 kw) |
| Fuel Type | Gas/LPG |
Operational
| Operating Weight | 11825.6 lb (5364 kg) |
| Fuel Capacity | 30.1 gal (113.6 L) |
| Hydraulic System Fluid Capacity | 30.1 gal (113.6 L) |
| Max Speed | 4 mph (6.4 km/h) |
| Tire Size | 10 x 31 |
| Tire Fill/Type | Foam-filled rough terrain |
