Tata Hitachi EX3600-5
Browse All Tata Hitachi or Shovel Models
Contents:
Backhoe Boom / Stick 1
| Max Dig Depth | 28.15 ft in (8580 mm) |
| Max Vertical Wall Dig Depth | 13.33 ft in (4060 mm) |
| Max Cutting Height | 58.04 ft in (17690 mm) |
| Max Dump Height | 38.03 ft in (11590 mm) |
| Backhoe Boom / Stick | Boom 31'6" (9600mm)/Stick 14'9" (4500mm) |
| Arm Crowd Force | _ - (951 Nm) |
| Max Reach On Ground | 57.75 ft in (17600 mm) |
Dimensions
| Width Over Tracks | _ - (6770 mm) |
| Length Of Track On Ground | 21.86 ft in (6660 mm) |
| Height To Top Of Cab | 25.43 ft in (7750 mm) |
| Ground Clearance | 2.97 in (905 mm) |
| Length Of Tracks | 28.55 ft in (8700 mm) |
| Height Of Tracks | _ - (2305 mm) |
| Upper Structure Ground Clearance | 8.34 ft in (2540 mm) |
Loading Shovel
| Max Dig Reach | 49.94 ft in (15220 mm) |
| Max Dump Height | 36.06 ft in (10990 mm) |
| Max Cutting Height | 53.48 ft in (16300 mm) |
| Max Dig Depth | 12.83 ft in (3910 mm) |
| Arm Crowd Force | _ - (1200 Nm) |
Undercarriage
| Loading Shovel Shoe Width | 50 in (1270 mm) |
| Loading Shovel Operating Weight | 767208.72 lb (348000 kg) |
| Loading Shovel Ground Pressure | 26.11 psi (180 kPa) |
| Max Travel Speed | 1.37 mph (2.21 km/h) |
| Backhoe Shoe Width 1 | 50 in (1270 mm) |
| Backhoe Operating Weight - Shoe 1 | 771617.97 lb (350000 kg) |
| Backhoe Ground Pressure - Shoe 1 | 26.26 psi (181 kPa) |
Engine
| Engine Make | 2243 |
| Engine Model | S16R-Y1TAA1 |
| Gross Power | 1877.5 hp (1400 kw) |
| Net Power | 1877.5 hp (1400 kw) |
| Displacement | 3991 cu in (65.4 L) |
Operational
| Fuel Capacity | 1902.1 gal (7200 L) |
| Swing Speed | 3.2 rpm |
