Terex RH340B
Contents:
Backhoe Boom / Stick 1
| Max Dig Depth | 29.2 ft in (8900 mm) |
| Max Cutting Height | 52.17 ft in (15900 mm) |
| Backhoe Boom / Stick | boom 34'5" (10500mm) w/ stick 16'6" (5000mm) |
Dimensions
| Width Over Tracks | 22.97 ft in (7000 mm) |
| Length Of Track On Ground | 23.27 ft in (7090 mm) |
| Height To Top Of Cab | 28.78 ft in (8770 mm) |
| Ground Clearance | 3.68 in (1120 mm) |
| Length Of Tracks | 30.29 ft in (9230 mm) |
| Height Of Tracks | 8.21 ft in (2500 mm) |
| Upper Structure Ground Clearance | 9.16 ft in (2790 mm) |
Loading Shovel
| Max Dig Reach | 53.81 ft in (16400 mm) |
| Max Dump Height | 38.06 ft in (11600 mm) |
| Max Cutting Height | 50.86 ft in (15500 mm) |
| Max Dig Depth | 8.86 ft in (2700 mm) |
| Loading Shovel | boom 26'2" (8000mm) w/ stick 16'9" ( 5100mm) |
Undercarriage
| Loading Shovel Shoe Width | 55.12 in (1400 mm) |
| Track Gauge | 18.38 ft in (5600 mm) |
| Loading Shovel Ground Pressure | 36.71 psi (253.04 kPa) |
| Max Travel Speed | 1.25 mph (2 km/h) |
| Number Of Lower Rollers | 7 |
| Number Of Track Shoes Per Side | 42 |
| Number Of Upper Rollers | 2 |
| Backhoe Shoe Width 1 | 55.12 in (1400 mm) |
| Backhoe Ground Pressure - Shoe 1 | 36.8 psi (253.73 kPa) |
| Backhoe Operating Weight - Shoe 1 | 1251123.41 lb (567500 kg) |
| Loading Shovel Operating Weight | 1249139.25 lb (566600 kg) |
Engine
| Number Of Cylinders | 12 |
| Engine Make | 2236 |
| Engine Model | 2 x 3512 C |
| Net Power | 3000 hp (2237.1 kw) |
| Gross Power | 3000 hp (2237.1 kw) |
| Power Measured @ | 1800 rpm |
| Displacement | 3574 cu in (58.6 L) |
| Aspiration | Turbocharged and air to air aftercooled |
Operational
| Fuel Capacity | 2948.2 gal (11160 L) |
| Hydraulic System Fluid Capacity | 1875.7 gal (7100 L) |
| Swing Speed | 3.9 rpm |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 300 amps |
