Case 450
Browse All Case or Skid Steer Loader Models
Contents:
Dimensions
| Length With Bucket | 11.74 ft in (3590 mm) |
| Width Over Tires | 5.38 ft in (1640 mm) |
| Ground Clearance | 9.1 in (231 mm) |
| Height To Top Of Cab | 6.67 ft in (2030 mm) |
| Wheelbase | 3.83 ft in (1170 mm) |
| Length W/O Bucket | 9.06 ft in (2770 mm) |
| Clearance At Max Lift And Dump | 7.88 ft in (2400 mm) |
| Reach At Max Lift And Dump | 26.7 in (678 mm) |
| Turning Radius From Center - Machine Rear | 62.2 in (1580 mm) |
| Turning Radius From Center - Inc Bucket | 84.3 in (2140 mm) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2239 |
| Engine Model | Family III 445T/M2, Tier II certified |
| Gross Power | 88 hp (65.7 kw) |
| Net Power | 82 hp (61.2 kw) |
| Power Measured @ | 2300 rpm |
| Aspiration | turbocharged |
| Displacement | 274 cu in (4.5 L) |
Operational
| Operational Weight | 8830 lb (4005 kg) |
| Fuel Capacity | 20.7 gal (78.3 L) |
| Cooling System Fluid Capacity | 4.5 gal (17 L) |
| Engine Oil Fluid Capacity | 3.2 gal (12 L) |
| Max Speed | 12.3 mph (19.8 km/h) |
| Hydraulic System Fluid Capacity | 17 gal (64.3 L) |
| Chain Box Fluid Capacity - Each Side | 2 gal (7.6 L) |
| Tire Size | 12.00 x 16.5 |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 95 amps |
Loader
| Breakout Force | 6200 lb (- -) |
| Operating Load Rating | 2450 lb (1111 kg) |
| Tipping Angle | 4900 degrees |
| Bucket Capacity | 0.7 yd3 (0.5 m3) |
Hydraulic
| Pump Type | Gear pump |
| Pump Flow Capacity | 22.1 gal/min (83.9 L/min) |
| Relief Valve Pressure | 3000 psi (20684.3 kPa) |
