JCB 210
Browse All JCB or Skid Steer Loader Models
Contents:
Dimensions
| Ground Clearance | 8.27 in (210 mm) |
| Wheelbase | 3.52 ft in (1070 mm) |
| Dig Depth | 393.71 in (10000 mm) |
| Dump Angle | 42 degrees |
| Dump Height | 7.42 ft in (2260 mm) |
| Loadover Height | 9317.59 ft in (2840 m) |
| Max. Reach @ Full Height | 3.97 ft in (1.21 m) |
| Overall Height | 6.5 ft in (1980 mm) |
| Overall Length | 137.41 in (3490 mm) |
| Pin Height | 9.85 ft in (3 m) |
| Quick Hitch Turning Radius | 3.75 ft in (1.14 m) |
| Reach @ Ground Level | 3.55 ft in (1.08 m) |
| Rear Chassis Turning Radius | 5.42 ft in (1.65 m) |
| Rollback - Ground Level | 30 degrees |
| Angle Of Departure | 25 degrees |
| Width Over Tyres | 59.85 in (1520 mm) |
| Bucket Corner Turning Radius | 6.86 ft in (2.09 m) |
Tyres
| Standard | 10 x 16.5 - 8 PR Xtra Wall Off Road |
Engine
| Emissions Certification | EPA-T4F (EU St3B) |
| Fuel | Diesel |
| Starter Motor | 2 KW |
| Battery | 12 V |
| Hydraulically Driven Cooling Fan | Yes |
| Engine Oil Service Interval | 500 hours |
| Engine Model | Kohler - KDI2504TCR/26A |
| Gross Power | 73.8 hp (55 kw) |
| Cooling System | Diesel |
| Power Measured @ | 2400 rpm |
| Max Torque | 221.3 lb ft (300 Nm) |
| Torque Measured @ | 1200 rpm |
| Aspiration | Turbo |
| Displacement | 2482 cu in (40.7 L) |
| Alternator | 100 amps |
Capacities
| Fuel Tank | 24.4 gal (92 L) |
| Hydraulic System | 11.5 gal (43.5 L) |
| Engine Oil | 2 gal (7.4 L) |
| Engine Coolant | 2.7 gal (10 L) |
Operational
| Sae Cab Operating Weight 1 | 6979.9 lb (3166 kg) |
| Sae Cab Operating Weight 2 | 7074.7 lb (3209 kg) |
| Roc With Full Counterweight | 2237.7 lb (1015 kg) |
| Operational Weight | 6885.1 lb (3123 kg) |
Transmission
| Model | Single Speed |
| Travel Speed | 7.5 mph (12 km/h) |
Loader
| Tipping Load - Full Counterweight | 4475.4 lb (2030 kg) |
| Loader Lift Capacity With Bucket | 4131.5 lb (1874 kg) |
| Tipping Load - No Counterweight | 4228.5 lb (1918 kg) |
| Breakout Force | 3964 lb (1798 kg) |
| Bucket Capacity | 0.5 yd3 (0.4 m3) |
| Bucket Width | 66.2 in (1680 mm) |
Hydraulic
| Pump Flow Capacity | 18.5 gal/min (70 L/min) |
| Relief Valve Pressure | 483.8 psi (3335 kPa) |
