John Deere 332
Browse All John Deere or Skid Steer Loader Models
Contents:
Dimensions
| Length With Bucket | 11.55 ft in (3518 mm) |
| Width Over Tires | 6.43 ft in (1958 mm) |
| Ground Clearance | 9.49 in (241 mm) |
| Height To Top Of Cab | 6.91 ft in (2106 mm) |
| Wheelbase | 4.05 ft in (1234 mm) |
| Length W/O Bucket | 9.63 ft in (2934 mm) |
| Clearance At Max Lift And Dump | 8.51 ft in (2591 mm) |
| Reach At Max Lift And Dump | 32.01 in (813 mm) |
| Turning Radius From Center - Inc Bucket | 83.71 in (2126 mm) |
Engine
| Number Of Cylinders | 5 |
| Engine Make | 2240 |
| Engine Model | 5030HW |
| Gross Power | 91 hp (67.9 kw) |
| Net Power | 85 hp (63.4 kw) |
| Power Measured @ | 2800 rpm |
| Aspiration | turbocharged |
| Displacement | 186 cu in (3.1 L) |
Operational
| Operational Weight | 9160 lb (4155 kg) |
| Fuel Capacity | 24 gal (90.9 L) |
| Max Speed | 11.2 mph (18 km/h) |
| Tire Size | 14x17.5 14 PR |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 70 amps |
Loader
| Breakout Force | 11600 lb (5261.7 kg) |
| Operating Load Rating | 3175 lb (1440.2 kg) |
| Tipping Angle | 6350 degrees |
| Bucket Capacity | 0.7 yd3 (0.5 m3) |
Hydraulic
| Pump Flow Capacity | 24.1 gal/min (91 L/min) |
| Relief Valve Pressure | 3100 psi (21373.8 kPa) |
