John Deere R4023
Browse All John Deere or Sprayer Models
Contents:
Boom
| Automatic Boom Height | BoomTrac Pro - 3 sensor (optional) |
| Boom Length Options | 18 or 24 m 60 or 80 ft |
| Boom Sections | Five |
| Breakaway Width | 1.83 m 6 ft |
| Ground Height Adjustment | 38 to 193 cm 15 to 76 in. |
| Plumbing Material | Polypropylene |
Engine
| Number Of Cylinders | 4 |
| Fuel Tank Capacity | 81.9 gal (310 L) |
| Displacement | 274.7 cu in (4.5 L) |
| Emission Level | Final Tier 4 |
| Peak Rated Power | 173 hp (129 kw) |
| Diesel Exhaust Fluid (Def) Tank Capacity | 4.5 gal (17 L) |
Drive Train
| Drive Train Type | Hydrostatic tandem Saur pumps Pump size is tandem - 75 cc 4.58 cu in. |
| Drive | Full-time four-wheel drive (4WD) |
| Shifting | Electrohydraulic (on the go) |
| Hydraulic Reservoir Capacity | 16.2 gal (61 L) |
| Spray Speed Range | 0 to 32 km/h 0 to 20 mph |
| Transport Speed, Maximum | 26.8 mph (43 km/h) |
Solution System
| Tank Material | Polyethylene |
| Rinse Tank Capacity | 70.1 gal (265 L) |
| Automatic Section Control | John Deere Section Control (optional) |
| Solution System Control | Manual |
| Fill Location | Side fill |
| Chemical Eductor | Stainless steel |
| Chemical Eductor Capacity (Size) | 5.3 gal (20 L) |
| Flow Meter Size | 2.1 in (5.1 cm) |
| Suction Strainer | 16 mesh |
| Pressure Strainer | 50 mesh |
| Boom Strainer | 80 mesh |
| Capacity | 607.6 gal (2300 L) |
| Quick Fill Size | 2.1 in (5.1 cm) |
Chassis
| Suspension | Air bar/shock suspended |
| Wheel Base | 146.9 in (373 cm) |
| Dry Compatible | No |
| Crop Clearance With Standard Tires | Narrow - 112 cm 44 in. Wide - 127 cm 50 in. |
| Front Tires | IF320/80R42, 380/R80R38, IF380/80R38, or 420/85R34 |
| Rear Tires | IF320/80R42, 380/R80R38, IF380/80R38, or 420/85R35 |
| Hydraulic Tread Adjust | Manual standard Hydraulic optional (wide only) |
| Wheel Tread Spacing | Narrow - 183 to 224 cm 72 to 88 in. Wide - 229 to 305 cm 90 to 120 in. |
| Turning Radius | 16.1 ft in (4.9 m) |
| Parking Brakes | Hydraulic release |
| Ladder Raise/Lower | Hydraulic |
| Total Weight With 80-Ft Boom | 18166.1 lb (8240 kg) |
| Primary Brakes | Hydrostatic |
