Case IH WD 2504
Contents:
Dimensions
| Length W/ Header | 23.59 ft in (7188 mm) |
| Height To Top Of Cab | 11.24 ft in (3424 mm) |
| Wheelbase | 144.06 in (3659 mm) |
| Length W/O Header | 16.59 ft in (5056 mm) |
| Track Width | 154.8 in, (3932 mm)Drive |
| Crop Clearance | 42.52 in (1080 mm) |
| Track Width (Engine End) | 90, 105 in,(2286, 2667 mm) |
| Weight, W/O Header | 12,500 to 13130 ib(5672 to 5957 kg) |
Speeds
| Maximum Road Speed | 19 mph (30.6 km/h) |
Engine
| Emission Tier Level | Tier 4B / Final |
| Radiator Core Type | Rotary Wand and duct |
| Fuel Tank | 31.8 gal (120 L) |
| Number Of Cylinders | 6 |
| Max. Horsepower | 261 hp (194.7 kw) |
| Def Tank Capacity | 19 gal (71.9 L) |
| Engine Make | Case IH FPT |
| Power | 250 hp (186.5 kw) |
| Displacement | 408.9 cu in (6.7 L) |
| Aspiration | Turbo, with charge air cooler |
| Alternator | 150 amps |
Transmission
| Transmission Type | Hydro static, 2-speed Standard |
Tires
| Tire Size Engine | 14Lx16.1 8PR or 16.5Lx16.1 8 PR |
| Cab Suspension | Standard |
| Drive Tires | 580/70 R26 R3 or 600/65 R28 R1W |
