Case TX1055
Browse All Case or Telescopic Forklift Models
Contents:
Dimensions
| Length To Fork Face | 21 ft in (6400 mm) |
| Ground Clearance | 1.67 ft in (509.02 mm) |
| Width Over Tires | 7.88 ft in (2400 mm) |
| Overall Height | 8.33 ft in (2538.99 mm) |
| Wheelbase | 10.83 ft in (3300 mm) |
| Turning Radius Outside Tires | 12.8 ft in (3900 mm) |
Lift
| Max Lift Height | 55 ft in (16764 mm) |
| Max Forward Reach | 40.42 ft in (12320.02 mm) |
| Max Load At Max Reach | 2000 lb (907.19 kg) |
| Max Load At Max Height | 5000 lb (2267.97 kg) |
| Max Lift Capacity | 10000 lb (4535.93 kg) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2239 |
| Engine Model | Family IV 4.5 L |
| Gross Power | 120 hp (89.5 kw) |
| Net Power | 108 hp (80.6 kw) |
| Power Measured @ | 2200 rpm |
| Max Torque | 379.9 lb ft (515 Nm) |
| Displacement | 276 cu in (4.6 L) |
| Aspiration | turbocharged |
Operational
| Operating Weight | 30754 lb (13949.8 kg) |
| Fuel Capacity | 36 gal (136.3 L) |
| Hydraulic System Fluid Capacity | 51.7 gal (195.8 L) |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 65 amps |
| Tire Size | 14.00 x 24 16PR |
Transmission
| Transmission Type | Powershift |
| Number Of Forward Gears | 4 |
| Max Speed - Forward | 21.5 mph (34.7 km/h) |
Hydraulic
| Pump Type | Gear |
| Pump Flow Capacity | 32 gal/min (121 L/min) |
