Case TX742
Browse All Case or Telescopic Forklift Models
Contents:
Dimensions
| Length To Fork Face | 20.08 ft in (6120.39 mm) |
| Ground Clearance | 1.86 ft in (47 mm) |
| Width Over Tires | 8 ft in (2438.4 mm) |
| Overall Height | 8.33 ft in (2538.99 mm) |
| Wheelbase | 10.18 ft in (3100 mm) |
| Turning Radius Outside Tires | 12.47 ft in (3800 mm) |
Lift
| Max Lift Height | 42 ft in (12801.6 mm) |
| Max Forward Reach | 28.88 ft in (8800 mm) |
| Max Load At Max Reach | 1300 lb (589.68 kg) |
| Max Load At Max Height | 3500 lb (1587.58 kg) |
| Max Lift Capacity | 6600 lb (2993.71 kg) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2239 |
| Engine Model | Family IV 4.5 L |
| Gross Power | 101 hp (75.4 kw) |
| Net Power | 95 hp (70.9 kw) |
| Power Measured @ | 2200 rpm |
| Max Torque | 295 lb ft (400 Nm) |
| Displacement | 276 cu in (4.6 L) |
| Aspiration | turbocharged |
Operational
| Operating Weight | 22700 lb (10296.6 kg) |
| Fuel Capacity | 36 gal (136.3 L) |
| Hydraulic System Fluid Capacity | 49 gal (185.5 L) |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 65 amps |
| Tire Size | 13.00 x 24 14PR |
Transmission
| Transmission Type | Powershift |
| Number Of Forward Gears | 4 |
| Number Of Reverse Gears | 4 |
| Max Speed - Forward | 21.5 mph (34.7 km/h) |
| Max Speed - Reverse | 21.5 mph (34.7 km/h) |
Hydraulic
| Pump Type | Gear |
| Pump Flow Capacity | 30 gal/min (113.6 L/min) |
