DIECI Pegasus 70.11
Browse All DIECI or Telescopic Forklift Models
Contents:
Lift
| Max Lift Height | 35.44 ft in (10800 mm) |
| Max Forward Reach | 28.88 ft in (8800 mm) |
| Max Lift Capacity | 15432.36 lb (7000 kg) |
| Max Load At Max Height | 6172.95 lb (2800 kg) |
| Max Load At Max Reach | 3306.94 lb (1500 kg) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2351 |
| Engine Model | 1104D-ETA |
| Gross Power | 142.2 hp (106 kw) |
| Power Measured @ | 2200 rpm |
| Displacement | 268.5 cu in (4.4 L) |
Operational
| Operating Weight | 35274 lb (16000 kg) |
| Fuel Capacity | 47.6 gal (180 L) |
| Hydraulic System Fluid Capacity | 71.4 gal (270 L) |
| Tire Size | 18-R22.5 (Industrial) |
Transmission
| Transmission Type | Hydrostatic with variable capacity pump |
| Max Speed - Forward | 24.9 mph (40 km/h) |
Hydraulic
| Pump Type | Double Gear pump |
| Pump Flow Capacity | 35.7 gal/min (135 L/min) |
| Relief Valve Pressure | 3335.9 psi (23000 kPa) |
