Landini Tele-Tractor
Browse All Landini or Telescopic Forklift Models
Contents:
Dimensions
| Length To Fork Face | 18.12 ft in (5520 mm) |
| Ground Clearance | 1.71 ft in (520 mm) |
| Width Over Tires | 7.68 ft in (2340 mm) |
| Wheelbase | 9.49 ft in (2890 mm) |
Lift
| Max Lift Height | 28.22 ft in (8600 mm) |
| Max Forward Reach | 18.38 ft in (5600 mm) |
| Max Lift Capacity | 7700 lb (3492.67 kg) |
| Max Load At Max Height | 7700 lb (3492.67 kg) |
| Max Load At Max Reach | 1980 lb (898.12 kg) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2367 |
| Engine Model | Euro2/Tier 2 |
| Gross Power | 150 hp (111.9 kw) |
| Net Power | 110 hp (82.1 kw) |
| Displacement | 268 cu in (4.4 L) |
Operational
| Operating Weight | 17600 lb (7983.3 kg) |
| Fuel Capacity | 32 gal (121.2 L) |
| Tire Size | 460/70 - 24 |
Transmission
| Transmission Type | Electronically-controlled |
| Number Of Forward Gears | 3 |
| Max Speed - Forward | 25 mph (40.3 km/h) |
Hydraulic
| Pump Type | Load-Sensing axial-piston hydraulic pump |
| Pump Flow Capacity | 26.3 gal/min (99.6 L/min) |
| Relief Valve Pressure | 4043 psi (27875.5 kPa) |
