Sunward SWTH3514
Browse All Sunward or Telescopic Forklift Models
Contents:
Dimensions
| Length To Fork Face | 20.79 ft in (6335 mm) |
| Ground Clearance | 17.96 ft in (456 mm) |
| Width Over Tires | 8.17 ft in (2490 mm) |
| Overall Height | 8.37 ft in (2550 mm) |
| Wheelbase | 9.68 ft in (2950 mm) |
Lift
| Max Lift Height | 44.79 ft in (13650 mm) |
| Max Forward Reach | 31.83 ft in (9700 mm) |
| Max Load At Max Reach | 1763.7 lb (800 kg) |
| Max Load At Max Height | 5511.56 lb (2500 kg) |
| Max Lift Capacity | 7716.18 lb (3500 kg) |
Engine
| Net Power | 100 hp (74.5 kw) |
| Aspiration | turbocharged |
Operational
| Operating Weight | 23721.8 lb (10760 kg) |
| Fuel Capacity | 31 gal (117 L) |
| Hydraulic System Fluid Capacity | 48.4 gal (183 L) |
| Tire Size | 405/70-24" |
Transmission
| Transmission Type | hydrostatic |
| Number Of Forward Gears | 2 |
| Number Of Reverse Gears | 2 |
| Max Speed - Forward | 21.8 mph (35 km/h) |
Hydraulic
| Pump Type | pistons variable displacement |
| Pump Flow Capacity | 37 gal/min (140 L/min) |
| Relief Valve Pressure | 3843.6 psi (26500 kPa) |
