Terex 4017
Browse All Terex or Telescopic Forklift Models
Contents:
Dimensions
| Length To Fork Face | 20.72 ft in (6315 mm) |
| Ground Clearance | 18.12 ft in (460 mm) |
| Width Over Tires | 7.83 ft in (2385 mm) |
| Overall Height | 8.42 ft in (2565 mm) |
| Wheelbase | 9.36 ft in (2850 mm) |
| Turning Radius Outside Tires | 13.1 ft in (3990 mm) |
Lift
| Max Lift Height | 54.9 ft in (16732 mm) |
| Max Forward Reach | 40.83 ft in (12442 mm) |
| Max Load At Max Reach | 1543.24 lb (700 kg) |
| Max Load At Max Height | 5511.56 lb (2500 kg) |
| Max Lift Capacity | 8818.5 lb (4000 kg) |
Engine
| Number Of Cylinders | 4 |
| Net Power | 101 hp (75.4 kw) |
| Aspiration | turbocharged |
Operational
| Operating Weight | 26235.1 lb (11900 kg) |
| Fuel Capacity | 35.7 gal (135 L) |
| Hydraulic System Fluid Capacity | 58.2 gal (220 L) |
| Tire Size | 400/70-20" PR16 |
Transmission
| Transmission Type | hydrostatic, 2-speed mechanical gearbox |
| Max Speed - Forward | 21.8 mph (35 km/h) |
| Max Speed - Reverse | 21.8 mph (35 km/h) |
Hydraulic
| Pump Type | fixed displacement |
| Pump Flow Capacity | 37 gal/min (140 L/min) |
| Relief Valve Pressure | 3626 psi (25000 kPa) |
