Kubota L2800 Gear
Browse All Kubota or Utility Tractor Models
Contents:
Dimensions
| Overall Length | 9.22 in (2810 mm) |
| Wheelbase | 5.29 ft in (1610 mm) |
| Overall Width | 4.29 ft in (1305 mm) |
| Height With Rops | 7.09 ft in (2160 mm) |
Engine
| Number Of Cylinders | 3 |
| Engine Make | 2334 |
| Engine Model | L2800 |
| Gross Power | 29 hp (21.7 kw) |
| Pto Power | 24 hp (17.9 kw) |
| Power Measured @ | 2800 rpm |
| Displacement | 85 cu in (1.4 L) |
Operational
| Operating Weight | 2359 lb (1070 kg) |
| Fuel Capacity | 9 gal (34 L) |
| 3 Point Hitch Lift Capacity @ 24 Inches | 1435.3 lb (651 kg) |
| Turning Radius | 7.9 ft in (2400 mm) |
| Tire Size Front - 2wd / 4wd | 5-15 |
| Rear Tires Size 2wd/4wd | 11.2-24 |
| Operating Voltage | 12 V |
Transmission
| Transmission Type | sliding gear constant mesh |
| Number Of Forward Gears | 8 |
| Number Of Reverse Gears | 4 |
| Max Speed | 13.7 mph (22 km/h) |
Hydraulic System
| Pump Flow Capacity | 6.6 gal/min (24.7 L/min) |
