Kubota L3830F
Browse All Kubota or Utility Tractor Models
Contents:
Dimensions
| Overall Length | 10.16 in (3095 mm) |
| Wheelbase | 6.06 ft in (1845 mm) |
| Overall Width | 5.55 ft in (1690 mm) |
| Ground Clearance | 14.77 in (375 mm) |
| Height With Out Rops | 7.08 ft in (2155 mm) |
| Height With Rops | 7.6 ft in (2315 mm) |
Engine
| Number Of Cylinders | 3 |
| Engine Make | 2334 |
| Engine Model | L3830 F |
| Net Power | 37.4 hp (27.9 kw) |
| Gross Power | 39 hp (29.1 kw) |
| Pto Power | 32 hp (23.9 kw) |
| Power Measured @ | 2700 rpm |
| Displacement | 111.5 cu in (1.9 L) |
Operational
| Operating Weight | 3152.7 lb (1430 kg) |
| Fuel Capacity | 10.6 gal (40 L) |
| 3 Point Hitch Lift Capacity @ 24 Inches | 2755.8 lb (1250 kg) |
| Turning Radius | 8.9 ft in (2700 mm) |
| Tire Size Front - 2wd / 4wd | 6.0-16 |
| Rear Tires Size 2wd/4wd | 14.9-24 |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 40 amps |
Transmission
| Transmission Type | FST |
| Number Of Forward Gears | 8 |
| Number Of Reverse Gears | 8 |
| Max Speed | 16 mph (25.7 km/h) |
Hydraulic System
| Pump Flow Capacity | 13.3 gal/min (50.1 L/min) |
