Yanmar LX4500
Browse All Yanmar or Utility Tractor Models
Contents:
Dimensions
| Overall Length | 124 in (3149.6 mm) |
| Wheelbase | 74.8 ft in (22799.04 mm) |
| Overall Width | 69.5 ft in (21183.6 mm) |
| Ground Clearance | 16.61 in (421.64 mm) |
| Weight | 3585 lb (1626.13 kg) |
Engine
| Number Of Cylinders | 4 |
| Gross Power | 45 hp (33.6 kw) |
| Lubrication | Full pressure |
| Cooling System | Liquid cooled |
| Air Cleaner | Dual element |
| Pto Power | 32.5 hp (24.3 kw) |
| Power Measured @ | 2700 rpm |
| Displacement | 133.6 cu in (2.2 L) |
| Bore | 3.5 in (88 mm) |
| Stroke | 3.6 in (90 mm) |
Capacities
| Front Axle | 536 cu in (8.8 L) |
| Fuel Tank | 11.9 gal (45.1 L) |
| Cooling System | 1.5 gal (5.4 L) |
| Transmission | 8.7 gal (33 L) |
| Engine Oil | 1.5 gal (5.4 L) |
Operational
| Tire Size Front - 2wd / 4wd | 8 – 16 in |
| Rear Tires Size 2wd/4wd | 14.9 – 24 in |
Power Take-Off(Pto)
| Pto Speed Rear | 540 rpm |
| Pto Type | Electro-hydraulic independent |
Hydraulic System
| Hydraulic System Type | Open center |
| Pump Type | Dual gear |
| Pump Flow Capacity | 9 gal/min (34.1 L/min) |
3-Point Hitch
| 3-Point Hitch | Telescopic Category 1 |
| Lift Capacity @ 24” | 2760 lb (1252 kg) |
