Ingersoll Rand SD105F
Browse All Ingersoll Rand or Vibratory Compactor Models
Contents:
Dimensions
| Overall Length W/O Blade | 19.34 ft in (5892 mm) |
| Width Over Tires | 7.5 ft in (2286 mm) |
| Height To Top Of Cab | 10.33 ft in (3146 mm) |
| Wheelbase | 10.18 in (3100 mm) |
Drum
| Drum Diameter | 59.02 in (1499 mm) |
| Centrifugal Force - High | 60698.42 lb (270 kN) |
| Pad Height | 4.02 in (102 mm) |
| Pad Surface Area | 21 in2 (13548.36 cm2) |
| Vibration Frequency 1 | 27.6 Hz |
| Vibratory Frequency 2 | 33.8 Hz |
| Number Of Pads | 120 |
| Centrifugal Force - Low | 58899.95 lb (262 kN) |
| Drum Width | 84.02 in (2134 mm) |
| Nominal Amplitude - High | 0.09 in (2.14 mm) |
| Nominal Amplitude - Low | 0.06 in (1.39 mm) |
Engine
| Engine Make | 2347 |
| Engine Model | B3.9 TAA Tier 2 |
| Net Power | 125 hp (93.3 kw) |
| Aspiration | turbocharged |
Operational
| Operating Weight | 25100 lb (11385.2 kg) |
| Fuel Capacity | 68 gal (257.5 L) |
| Hydraulic System Fluid Capacity | 22 gal (83.3 L) |
| Max Speed | 6.5 mph (10.3 km/h) |
| Tires | 23.1x26 8PR R1 |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 95 amps |
