Caterpillar CS323
Browse All Caterpillar or Vibratory Smooth Drum Roller Models
Contents:
Dimensions
| Overall Length | 13.92 in (4240 mm) |
| Overall Width | 4.6 ft in (1400 mm) |
| Height To Top Of Cab | 9.84 ft in (2997 mm) |
Engine
| Engine Make | 2351 |
| Engine Model | 4.236 |
| Gross Power | 77 hp (57.5 kw) |
| Displacement | 236.2 cu in (3.9 L) |
Operational
| Operating Weight | 9199.9 lb (4173 kg) |
| Fuel Capacity | 31.8 gal (120 L) |
| Engine Oil Capacity | 2 gal (7.3 L) |
| Hydraulic System Fluid Capacity | 31.8 gal (120 L) |
| Max Speed | 6.6 mph (10.5 km/h) |
| Tires *If Applicable | 9.5x24 |
Drum
| Drum Width | 48.1 in (1220 mm) |
| Drum Diameter | 38.2 in (970 mm) |
| Vibration Frequency 1 | 30 Hz |
| Centrifugal Force - Med | 12700 lb (56.5 kN) |
