Dynapac CC1300C
Browse All Dynapac or Vibratory Smooth Drum Roller Models
Contents:
Dimensions
| Overall Length | 107 in (2717.8 mm) |
| Overall Width | 4.17 ft in (1270 mm) |
| Height To Top Of Cab | 9 ft in (2743.2 mm) |
| Wheelbase | 76 in (1930.4 mm) |
| Ground Clearance | 10 in (254 mm) |
| Gradeability | 37 % |
| Overhang Front | 0.17 ft in (50.8 mm) |
| Overhang Rear | 0.17 ft in (50.8 mm) |
| Turning Radius - Inside | 9.67 ft in (2946.4 mm) |
| Turning Radius - Outside | 13.92 ft in (4241.8 mm) |
| Curb Clearance | 24 in (609.6 mm) |
Engine
| Emissions Certification | Tier 4i |
| Engine Make | Kubota |
| Engine Model | V2203-M |
| Engine Type | Water cooled |
| Gross Power | 45 hp (33.6 kw) |
| Power Measured @ | 2600 rpm |
Operational
| Operating Weight Rops | 8300 lb (3764.9 kg) |
| Operating Weight | 8600 lb (3900.9 kg) |
| Fuel Capacity | 13 gal (49.3 L) |
| Engine Oil Capacity | 10.6 gal (40.2 L) |
| Water Spray System Fluid Capacity | 53 gal (200.7 L) |
| Max Speed | 6.3 mph (10 km/h) |
| Steering Angle | 30 degrees |
Drum
| Drum Thickness | 0.6 in (15.3 mm) |
| Drum Width | 51 in (1295.4 mm) |
| Drum Diameter | 32 in (812.8 mm) |
| Static Linear Load | 83 lb/in (14.9 kg/cm) |
| Vibration Frequency 1 | 53 Hz |
| Nominal Amplitude - High | 0.1 in (0.6 mm) |
| Centrifugal Force - High | 8100 lb (36.1 kN) |
Tires
| Standard | 7.50-16 |
| Track Widths | 9 in (228.6 mm) |
| Wheel Track/Tire Overlap | 5 in (127 mm) |
Brakes
| Parking Brake | Failsafe multidisc brake on drum and wheels |
| Service Brake | Hydrostatic in forward and reverse lever |
