Hamm 3518
Browse All Hamm or Vibratory Smooth Drum Roller Models
Contents:
Dimensions
| Overall Length | 244.49 in (6210 mm) |
| Height To Top Of Cab | 9.78 ft in (2980 mm) |
| Wheelbase | 124.61 in (3165 mm) |
| Ground Clearance | 16.74 in (425 mm) |
| Angle Of Driving Slope-Front | 34 degrees |
| Width Over Cab | 94.1 in (2390 mm) |
| Angle Of Driving Slope-Rear | 27 degrees |
| Loadover Height | 7.63 ft in (2.33 m) |
| Turning Radius - Inside | 13.72 ft in (4180 mm) |
Steering System
| Steering Method | Articulated steering |
| Oscillating Angle | 10 degrees |
Speeds
| Speed - Working Gear | 7 mph (11.3 km/h) |
| Speed - Transportation Gear | 11 mph (17.8 km/h) |
| Size Of Tyres, Rear | AW 23.1-26 12 PR |
Engine
| Emissions Certification | EU Stage IIIA / EPA Tier 3 |
| Engine Power@Iso 14396 | 207.9 hp (155 kw) |
| Engine Power@Saej1349 | 207.9 hp (155 kw) |
| Number Of Cylinders | 6 |
| Engine Make | Deutz |
| Engine Model | TCD 2012 L04 2V |
| Power Measured @ | 2300 rpm |
Operational
| Operating Weight Cabin | 39297.4 lb (17825 kg) |
| Operating Weight Rops | 38812.4 lb (17605 kg) |
| Fuel Capacity | 76.7 gal (290 L) |
| Max Weight | 47223.1 lb (21420 kg) |
| Axle Load - Front | 20514.1 lb (9305 kg) |
| Axle Load - Rear | 14219.9 lb (6450 kg) |
Drum
| Drum Thickness | 1.8 in (45 mm) |
| Drum Type | smooth |
| Drum Width | 87.5 in (2220 mm) |
| Drum Diameter | 63 in (1600 mm) |
| Static Linear Load | 272.2 lb/in (48.6 kg/cm) |
| Vibration Frequency 1 | 27 Hz |
| Nominal Amplitude - High | 0.1 in (2 mm) |
| Vibration Frequency 2 | 30 Hz |
| Nominal Amplitude - Low | 0.1 in (1.2 mm) |
| Centrifugal Force - High | 54628.6 lb (243 kN) |
| Centrifugal Force - Low | 54628.6 lb (243 kN) |
