Hamm HD PLUS 140i VV
Browse All Hamm or Vibratory Smooth Drum Roller Models
Contents:
Dimensions
| Overall Length | 208.67 in (5300 mm) |
| Overall Width | 7.42 ft in (2260 mm) |
| Height To Top Of Cab | 9.78 ft in (2980 mm) |
| Wheelbase | 153.55 in (3900 mm) |
| Ground Clearance | 35.44 in (900 mm) |
| Track Width | 7.42 ft in (2.26 m) |
| Turning Radius - Inside | 20.35 ft in (6200 mm) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | DEUTZ |
| Engine Model | TCD 4.1 L4 |
| Gross Power | 154.3 hp (115 kw) |
| Net Power | 154.3 hp (115 kw) |
Operational
| Operating Weight Cabin | 28340.5 lb (12855 kg) |
| Operating Weight Rops | 27811.4 lb (12615 kg) |
| Operating Weight | 30357.7 lb (13770 kg) |
| Fuel Capacity | 68.7 gal (260 L) |
| Water Spray Tank Fluid Capacity | 302.5 gal (1145 L) |
| Max Speed | 3.8 mph (6 km/h) |
| Steering Angle | 10 degrees |
Drum
| Drum Thickness | 0.8 in (19 mm) |
| Drum Width | 84.3 in (2140 mm) |
| Drum Diameter | 55.2 in (1400 mm) |
| Nominal Amplitude - High | 0.1 in (0.9 mm) |
| Nominal Amplitude - Low | 0.1 in (0.4 mm) |
| Centrifugal Force - High | 40465.7 lb (180 kN) |
| Centrifugal Force - Low | 21356.9 lb (95 kN) |
