Hypac C840D
Contents:
| Overall Length | 19.17 in (5840 mm) |
| Height To Top Of Cab | 9.76 ft in (2972 mm) |
| Wheelbase | 9.72 in (2960 mm) |
| Ground Clearance | 19.3 in (490 mm) |
| Number Of Cylinders | 4 |
| Engine Make | 2349 |
| Engine Model | TCD2013L042V |
| Gross Power | 133 hp (99.2 kw) |
| Power Measured @ | 2200 rpm |
| Operating Weight | 22930 lb (10400.9 kg) |
| Fuel Capacity | 66.1 gal (250 L) |
| Max Speed | 8.4 mph (13.5 km/h) |
| Tires *If Applicable | 23.1-26/12PR |
| Operating Voltage | 12 V |
| Drum Width | 83.9 in (2130 mm) |
| Drum Diameter | 59.1 in (1500 mm) |
| Static Linear Load | 159.6 lb/in (28.5 kg/cm) |
| Vibration Frequency 1 | 30 Hz |
| Nominal Amplitude - Med | 0.1 in (1.8 mm) |
| Vibration Frequency 2 | 36 Hz |
| Centrifugal Force - Med | 53055 lb (236 kN) |
