Caterpillar 924H
Browse All Caterpillar or Wheel Loader Models
Contents:
Bucket
| Dump Clearance At Max Raise | 9.25 ft in (2828 mm) |
| Bucket Capacity - Heaped | 2 yd3 (1.5 m3) |
| Bucket Width | 8.33 ft in (2550 mm) |
| Breakout Force | 21731 lb (9857 kN) |
Dimensions
| Ground Clearance | 1.43 ft in (436 mm) |
| Length With Bucket On Ground | 23.45 ft in (7147 mm) |
| Width Over Tires | 8.18 ft in (2492 mm) |
| Height To Top Of Cab | 10.59 ft in (3227 mm) |
| Wheelbase | 9.19 ft in (2800 mm) |
| Hinge Pin - Max Height | 12.9 ft in (3881 mm) |
| Reach At Max Lift And Dump | 3.26 ft in (992 mm) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2236 |
| Engine Model | C6.6 |
| Net Power | 128 hp (96 kw) |
| Power Measured @ | 2300 rpm |
| Max Torque | 496 lb ft (673 Nm) |
| Displacement | 403 cu in (6.6 L) |
Operational
| Operating Weight | 25644 lb (11632 kg) |
| Fuel Capacity | 59.4 gal (225 L) |
| Hydraulic System Fluid Capacity | 39 gal (148 L) |
| Cooling System Fluid Capacity | 10.6 gal (40 L) |
| Transmission Fluid Capacity | 6.1 gal (23 L) |
| Front Axle/Diff Fluid Capacity | 5.5 gal (21 L) |
| Rear Axle/Diff Fluid Capacity | 5.5 gal (21 L) |
| Static Tipping Weight | 16041 lb (7276 kg) |
| Turning Radius | 18.2 ft in (5530 mm) |
| Tire Size | 20.5 R25 |
Transmission
| Transmission Type | Standard |
| Number Of Forward Gears | 4 |
| Number Of Reverse Gears | 3 |
| Max Speed - Forward | 23.9 mph (38.5 km/h) |
| Max Speed - Reverse | 13.5 mph (21.8 km/h) |
Hydraulic System
| Relief Valve Setting | 3755 psi (25900 kPa) |
| Pump Flow Capacity | 4015 gal/min (152 L/min) |
| Raise Time | 5.1 sec |
| Dump Time | 1.4 sec |
| Lower Time | 2.4 sec |
| Pump Type | Implement Pump |
