| Number Of Cylinders | 6 |
| Engine Make | 2236 |
| Engine Model | CAT C13 ACERT |
| Net Power | 378 hp (281.9 kw) |
| Gross Power | 417 hp (311 kw) |
| Max Torque | 1617 lb ft (2192.4 Nm) |
| Net Power - Iso 9249 | 386 hp (287.9 kw) |
| Engine Model | Cat? C13 ACERT? |
| Note | The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 1.6 kg of refrigerant which has a CO2 equivalent of 2.288 metric tonnes. |
| Peak Gross Torque - 1,200 Rpm - Sae J1995 | 1627 lb ft (2206 Nm) |
| Peak Gross Torque - 1,200 Rpm - Iso 14396 | 1609 lb ft (2181.6 Nm) |
| Maximum Net Power - 1,700 Rpm - Iso 9249 | 386 hp (287.9 kw) |
| Maximum Net Torque - 1,100 Rpm | 1515 lb ft (2054.1 Nm) |
| Maximum Power - 1,700 Rpm - Iso 14396 | 420 hp (313.2 kw) |
| Maximum Power - 1,700 Rpm - Iso 14396 - Metric | 426 hp (317.7 kw) |
| Maximum Net Power - 1,700 Rpm - Iso 9249 - Metric | 392 hp (292.4 kw) |
| Maximum Net Power - 1,700 Rpm - Sae J1349 | 386 hp (287.9 kw) |
| Maximum Net Power - 1,700 Rpm - Sae J1349 - Metric | 392 hp (292.4 kw) |
| Maximum Power - 1,700 Rpm - Sae J1995 | 425 hp (317 kw) |
| Maximum Power - 1,700 Rpm - Sae J1995 - Metric | 431 hp (321.4 kw) |
| Maximum Net Torque - 1,000 Rpm | 1505 lb ft (2040.6 Nm) |
| Maximum Power - 1,800 Rpm - Iso 14396 | 406 hp (302.8 kw) |
| Maximum Power - 1,800 Rpm - Iso 14396 - Metric | 412 hp (307.3 kw) |
| Maximum Power - 1,800 Rpm - Sae J1995 | 412 hp (307.3 kw) |
| Maximum Power - 1,800 Rpm - Sae J1995 - Metric | 417 hp (311 kw) |
| Peak Gross Torque - 1,300 Rpm - Sae J1995 | 1617 lb ft (2192.4 Nm) |
| Maximum Net Power - 1,800 Rpm - Iso 9249 | 373 hp (278.2 kw) |
| Maximum Net Power - 1,800 Rpm - Sae J1349 | 373 hp (278.2 kw) |
| Maximum Net Power - 1,800 Rpm - Iso 9249 - Metric | 378 hp (281.9 kw) |
| Maximum Net Power - 1,800 Rpm - Sae J1349 - Metric | 378 hp (281.9 kw) |
| Peak Gross Torque - 1,300 Rpm - Iso 14396 | 1602 lb ft (2172.1 Nm) |
| U.S. Epa Tier 4 Final/Eu Stage Iv - Maximum Power - Sae J1995 | 425 hp (317 kw) |
| Tier 2/Stage Ii, Tier 3/Stage Iiia Equivalent: Maximum Power - Sae J1995 | 412 hp (307.3 kw) |
| Operating Weight | 66337 lb (30090 kg) |
| Note | Weight based on a machine configuration with Michelin 29.5R25 XLDD1 L4 radial tires, full fluids, operator, standard counterweight, cold start, roading fenders, Product Link?, open differential axles, secondary steering, sound suppression, and a 5.4 m3 (7.1 yd3) GP bucket with BOCE. |
| Note (1) | For 5.4 m3 (7.1 yd3) general purpose buckets with BOCE. |
| Note (2) | Weight based on a machine configuration with Michelin 29.5R25 XLDD1 L4 radial tires, full fluids, operator, standard counterweight, cold start, roading fenders, Product Link, open differential axles (front/rear), secondary steering, sound suppression, and a 5.4 m3 (7.1 yd3) general purpose bucket with BOCE. |
| Hydraulic Cycle Time - Total | 10.1 s |
| Implement System - Maximum Operating Pressure | 4975 psi |
| Implement Pump Type | Variable Displacement Piston |
| Implement System - Maximum Pump Output At 2,250 Rpm | 119 gal/min |
| Implement System - Optional 3rd Function Maximum Flow | 63 gal/min |
| Implement System - Optional 3rd Function Maximum Pressure | 3159 psi |
| Hydraulic Cycle Time - Rated Payload - Raise From Carry Position | 5.3 s |
| Hydraulic Cycle Time - Rated Payload - Dump, At Maximum Raise | 1.7 s |
| Hydraulic Cycle Time - Rated Payload - Lower, Empty, Float Down | 3.1 s |
| Hydraulic Cycle Time - Rated Payload - Total | 10.1 s |
| Note (1) | *Distance of 15 m (49.2 ft), moving forward in second gear ratio. |
| Note (2) | **For machines in European Union countries and in countries that adopt the ?EU Directives.? |
| Note (3) | ***European Union Directive ?2000/14/EC? as amended by ?2005/88/EC.? |
| Note | *Distance of 15 m (49.2 ft), moving forward in second gear ratio. |
| With Cooling Fan Speed At Maximum Value - Operator Sound Pressure Level (Iso 6396:2008) | 75 dB(A) |
| With Cooling Fan Speed At Maximum Value - Exterior Sound Power Level (Iso 6395:2008) | 112 dB(A) |
| With Cooling Fan Speed At Maximum Value - Exterior Sound Pressure Level (Sae J88:2013) | 78 dB(A)* |
| With Cooling Fan Speed At 70% Of Maximum Value - Operator Sound Pressure Level (Iso 6396:2008)** | 72 dB(A) |
| With Cooling Fan Speed At 70% Of Maximum Value - Exterior Sound Power Level (Iso 6395:2008)** | 109 LWA*** |
| Emissions | Cat engine with ACERT Technology ? meets Tier 4 Final/Stage IV emission standards. |
| Engine Model | Cat C13 ACERT |
| Maximum Net Power - 1,700 Rpm - Sae J1349 | 386 hp (287.9 kw) |
| Peak Gross Torque - 1,200 Rpm - Sae J1995 | 1627 lb ft (2206 Nm) |
| Bore | 5.2 in (130.1 mm) |
| Stroke | 6.2 in (157 mm) |
| Displacement | 763 cu in (12.6 L) |
| Note (1) | The power ratings apply at the stated speed when tested under the reference conditions for the specified standards. |
| Note (2) | The net power advertised is the power available at the flywheel when the engine is equipped with fan, alternator, air cleaner and aftertreatment. |
| Note (3) | The gross power advertised is with the fan at maximum speed. |
| Maximum Net Torque - 1,100 Rpm - Sae J1349 | 1515 lb ft (2054.1 Nm) |
| Maximum Power - 1,700 Rpm - Sae J1995 | 425 hp (317 kw) |
| Operator Sound Pressure Level - Iso 6396:2008 | 75 dB(A) |
| Exterior Sound Power Level - Iso 6395:2008* | 112 dB(A) |
| Exterior Sound Pressure Level - Sae J88:2013** | 78 dB(A) |
| Note (1) | The sound values indicated are for specific operating conditions only. Machine and operator sound levels will vary at different engine and/or cooling fan speeds. Hearing protection may be needed when the machine is operated with a cabin that is not properly maintained, or when the doors and/or windows are open for extended periods or in a noisy environment. |
| Note (2) | *For a standard machine configuration, measured according to the procedures specified with the cooling fan speed set at maximum value. |
| Note (3) | **For a standard machine configuration, measured according to the procedures specified. The measurement was conducted under the following conditions: distance of 15 m (49.2 ft), moving forward in second gear ratio with the cooling fan speed set at maximum value. |
| Note (1) | The sound values indicated are for specific operating conditions only. Machine and operator sound levels will vary at different engine and/or cooling fan speeds. Hearing protection may be needed when the machine is operated with a cabin that is not properly maintained, or when the doors and/or windows are open for extended periods or in a noisy environment. |
| Operator Sound Pressure Level - Iso 6396:2008 | 72 dB(A) |
| Exterior Sound Power Level - Iso 6395:2008* | 112 dB(A) |
| Exterior Sound Pressure Level - Sae J88:2013** | 78 dB(A) |
| Note (2) | *For a standard machine configuration, measured according to the procedures specified with the cooling fan speed set at maximum value. |
| Note (3) | **For a standard machine configuration, measured according to the procedures specified. The measurement was conducted under the following conditions: distance of 15 m (49.2 ft), moving forward in second gear ratio with the cooling fan speed set at maximum value. |
