John Deere 444J Powerllel w/Coupler
Browse All John Deere or Wheel Loader Models
Contents:
Bucket
| Dump Clearance At Max Raise | 8.58 ft in (2620 mm) |
| Breakout Force | 14770 lb (65.7 kN) |
| Bucket Capacity - Heaped | 2.5 yd3 (1.9 m3) |
| Bucket Capacity - Struck | 2.1 yd3 (1.6 m3) |
| Bucket Width | 8.33 ft in (2538.99 mm) |
Dimensions
| Ground Clearance | 1.3 ft in (396 mm) |
| Length With Bucket On Ground | 23.42 ft in (7140 mm) |
| Height To Top Of Cab | 10.42 ft in (3180 mm) |
| Wheelbase | 9 ft in (2740 mm) |
| Hinge Pin - Max Height | 12 ft in (3660 mm) |
| Reach At Max Lift And Dump | 4.17 ft in (1280 mm) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2240 |
| Engine Model | 4045H |
| Net Power | 119 hp (89 kw) |
| Power Measured @ | 2200 rpm |
| Max Torque | 380 lb ft (515 Nm) |
| Displacement | 276 cu in (4.5 L) |
| Torque Measured @ | 1400 rpm |
| Aspiration | Turbocharged charge air cooled |
| Torque Rise | 32 % |
Operational
| Operating Weight | 26650 lb (12088 kg) |
| Fuel Capacity | 65 gal (246 L) |
| Hydraulic System Fluid Capacity | 25.5 gal (96.5 L) |
| Engine Oil Fluid Capacity | 4.7 gal (17.5 L) |
| Cooling System Fluid Capacity | 5.1 gal (19 L) |
| Transmission Fluid Capacity | 4.9 gal (18.5 L) |
| Front Axle/Diff Fluid Capacity | 5.9 gal (22 L) |
| Rear Axle/Diff Fluid Capacity | 5.9 gal (22 L) |
| Static Tipping Weight | 16621 lb (7539 kg) |
| Turning Radius | 15.5 ft in (4700.1 mm) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 80 amps |
| Rear Axle Oscillation | 24 degrees |
| Tire Size | 17.5 R25 |
Transmission
| Transmission Type | Automatic Powershift |
| Number Of Forward Gears | 4 |
| Number Of Reverse Gears | 3 |
| Max Speed - Forward | 23.4 mph (37.7 km/h) |
| Max Speed - Reverse | 15.7 mph (25.3 km/h) |
Hydraulic System
| Relief Valve Setting | 3600 psi (24800 kPa) |
| Pump Flow Capacity | 37 gal/min (140 L/min) |
| Raise Time | 5.5 sec |
| Dump Time | 1.1 sec |
| Lower Time | 1.9 sec |
| Pump Type | Variable axial piston |
