Kawasaki 65ZIV
Browse All Kawasaki or Wheel Loader Models
Contents:
Bucket
| Dump Clearance At Max Raise | 8.85 ft in (2695 mm) |
| Bucket Capacity - Heaped | 2.62 yd3 (2 m3) |
| Bucket Capacity - Struck | 2.23 yd3 (1.7 m3) |
| Bucket Width | 8.04 ft in (2450 mm) |
| Breakout Force | 21400 lb (95.2 kN) |
Dimensions
| Ground Clearance | 1.24 ft in (375 mm) |
| Length With Bucket On Ground | 23 ft in (7010 mm) |
| Width Over Tires | 7.8 ft in (2375 mm) |
| Height To Top Of Cab | 10.47 ft in (3190 mm) |
| Wheelbase | 9.52 ft in (2900 mm) |
| Hinge Pin - Max Height | 11.85 ft in (3610 mm) |
| Reach At Max Lift And Dump | 3.66 ft in (1115 mm) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2347 |
| Engine Model | B5.9-C |
| Net Power | 134 hp (100 kw) |
| Power Measured @ | 2400 rpm |
| Max Torque | 383 lb ft (519.3 Nm) |
| Displacement | 359 cu in (5.9 L) |
| Torque Measured @ | 1400 rpm |
| Aspiration | natural |
Operational
| Operating Weight | 22509.2 lb (10210 kg) |
| Fuel Capacity | 47.6 gal (180 L) |
| Hydraulic System Fluid Capacity | 26.5 gal (100 L) |
| Engine Oil Fluid Capacity | 3.8 gal (14.2 L) |
| Cooling System Fluid Capacity | 11.2 gal (42.2 L) |
| Transmission Fluid Capacity | 8 gal (30 L) |
| Front Axle/Diff Fluid Capacity | 6.7 gal (25 L) |
| Rear Axle/Diff Fluid Capacity | 6.7 gal (25 L) |
| Static Tipping Weight | 17747.3 lb (8050 kg) |
| Turning Radius | 18.8 ft in (5710 mm) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 50 amps |
| Rear Axle Oscillation | 24 degrees |
| Tire Size | 17.5x25-12PR (L-2) |
Transmission
| Transmission Type | full powershift |
| Number Of Forward Gears | 4 |
| Number Of Reverse Gears | 4 |
| Max Speed - Forward | 23.1 mph (37.2 km/h) |
| Max Speed - Reverse | 23.1 mph (37.2 km/h) |
Hydraulic System
| Relief Valve Setting | 2770 psi (19098.5 kPa) |
| Pump Flow Capacity | 15.3 gal/min (58 L/min) |
| Raise Time | 5.8 sec |
| Dump Time | 1.2 sec |
| Lower Time | 2.9 sec |
| Pump Type | gear type |
