Kawasaki 90ZIII
Browse All Kawasaki or Wheel Loader Models
Contents:
Bucket
| Dump Clearance At Max Raise | 9.91 ft in (3020 mm) |
| Bucket Capacity - Heaped | 4.98 yd3 (3.8 m3) |
| Bucket Capacity - Struck | 4.26 yd3 (3.25 m3) |
| Bucket Width | 10.18 ft in (3100 mm) |
| Breakout Force | 43870 lb (195.15 kN) |
Dimensions
| Ground Clearance | 1.69 ft in (515 mm) |
| Length With Bucket On Ground | 27.47 ft in (8370 mm) |
| Width Over Tires | 9.62 ft in (2930 mm) |
| Height To Top Of Cab | 11.59 ft in (3530 mm) |
| Wheelbase | 11.16 ft in (3400 mm) |
| Hinge Pin - Max Height | 13.98 ft in (4260 mm) |
| Reach At Max Lift And Dump | 4.07 ft in (1240 mm) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2347 |
| Engine Model | LTA-10-C290 |
| Net Power | 256 hp (190.9 kw) |
| Power Measured @ | 2100 rpm |
| Max Torque | 832 lb ft (1128.1 Nm) |
| Displacement | 611 cu in (10.1 L) |
| Torque Measured @ | 1300 rpm |
| Aspiration | turbocharged & after cooled |
Operational
| Operating Weight | 47994.7 lb (21770 kg) |
| Fuel Capacity | 81.9 gal (310 L) |
| Hydraulic System Fluid Capacity | 43.6 gal (165 L) |
| Engine Oil Fluid Capacity | 11.7 gal (44 L) |
| Cooling System Fluid Capacity | 14.8 gal (56 L) |
| Transmission Fluid Capacity | 15.9 gal (60 L) |
| Front Axle/Diff Fluid Capacity | 14.6 gal (55 L) |
| Rear Axle/Diff Fluid Capacity | 14.6 gal (55 L) |
| Static Tipping Weight | 35274 lb (16000 kg) |
| Turning Radius | 22.4 ft in (6825 mm) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 75 amps |
| Rear Axle Oscillation | 24 degrees |
| Tire Size | 26.5-25-20PR (L-3) |
Transmission
| Transmission Type | full power shift |
| Number Of Forward Gears | 4 |
| Number Of Reverse Gears | 4 |
| Max Speed - Forward | 20.5 mph (33 km/h) |
| Max Speed - Reverse | 20.8 mph (33.5 km/h) |
Hydraulic System
| Relief Valve Setting | 3000 psi (20684.3 kPa) |
| Pump Flow Capacity | 37 gal/min (140.1 L/min) |
| Raise Time | 6.1 sec |
| Dump Time | 1.6 sec |
| Lower Time | 3 sec |
| Pump Type | gear type |
