Manitou ML40
Browse All Manitou or Wheel Loader Models
Contents:
Bucket
| Dump Clearance At Max Raise | 6.4 ft in (1950 mm) |
| Bucket Width | 4.27 ft in (1300 mm) |
Dimensions
| Ground Clearance | 0.79 ft in (240 mm) |
| Length With Bucket On Ground | 14.51 ft in (4420 mm) |
| Height To Top Of Cab | 6.44 ft in (1960 mm) |
| Wheelbase | 5.58 ft in (1700 mm) |
| Hinge Pin - Max Height | 8.86 ft in (2700 mm) |
Engine
| Engine Make | 2334 |
| Gross Power | 51 hp (38 kw) |
| Max Torque | 105.5 lb ft (143 Nm) |
| Aspiration | turbocharged |
Operational
| Operating Weight | 6393.5 lb (2900 kg) |
| Fuel Capacity | 15.9 gal (60 L) |
| Turning Radius | 10.4 ft in (3160 mm) |
| Tire Size | 10x16.5 10PR SKS |
Transmission
| Transmission Type | hydrostatic |
| Number Of Forward Gears | 1 |
| Number Of Reverse Gears | 1 |
| Max Speed - Forward | 13.7 mph (22 km/h) |
Hydraulic System
| Relief Valve Setting | 3335.9 psi (23000 kPa) |
| Pump Flow Capacity | 13.3 gal/min (50 L/min) |
| Pump Type | gear |
