Mustang ML28
Browse All Mustang or Wheel Loader Models
Contents:
Bucket
| Dump Clearance At Max Raise | 7.58 ft in (2311 mm) |
| Bucket Capacity - Heaped | 1.44 yd3 (1.11 m3) |
| Bucket Capacity - Struck | 0.85 yd3 (0.65 m3) |
| Bucket Width | 5.42 ft in (1650 mm) |
| Breakout Force | 6.14 lb (28 kN) |
Dimensions
| Ground Clearance | 1.08 ft in (330 mm) |
| Length With Bucket On Ground | 15.67 ft in (4780 mm) |
| Width Over Tires | 4.92 ft in (1500 mm) |
| Height To Top Of Cab | 7.67 ft in (2340 mm) |
| Wheelbase | 5.75 ft in (1750 mm) |
| Hinge Pin - Max Height | 9.92 ft in (3022 mm) |
| Reach At Max Lift And Dump | 0.84 ft in (254 mm) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2348 |
| Engine Model | 4TNV88 |
| Net Power | 39 hp (29.1 kw) |
| Gross Power | 48 hp (35.8 kw) |
| Power Measured @ | 2400 rpm |
| Displacement | 133.6 cu in (2.2 L) |
Operational
| Operating Weight | 7055 lb (3200 kg) |
| Fuel Capacity | 15.9 gal (60.2 L) |
| Static Tipping Weight | 5181 lb (2350 kg) |
| Turning Radius | 11.2 ft in (3400 mm) |
| Rear Axle Oscillation | 38 degrees |
| Tire Size | 12.0 - 18 |
Transmission
| Transmission Type | Hydrostatic |
| Max Speed - Forward | 12.4 mph (20 km/h) |
| Max Speed - Reverse | 12.4 mph (20 km/h) |
Hydraulic System
| Relief Valve Setting | 3336 psi (23000.9 kPa) |
| Pump Flow Capacity | 13.7 gal/min (52 L/min) |
