| Wheelbase | 6.81 ft in (2075 mm) |
| Dig Depth | 2.88 in (73 mm) |
| Dump Height - Fully Raised, 45° Dump | 98.04 in (2490 mm) |
| Ground Clearance Under Axles | 12.64 in (321 mm) |
| Angle Of Departure | 28 degrees |
| Hinge Pin Height - Fully Raised | 123.47 in (3136 mm) |
| Operating Height - Fully Raised With Spillgaurd | 55.12 in (1400 mm) |
| Overall Length - Bucket Level On Ground | 208 in (5283 mm) |
| Overall Width Without Bucket | 68.51 in (1740 mm) |
| Rear Axle Oscillation, Total | 18 degrees |
| Total Angle | 80 degrees |
| Tread Width | 55.12 in (1400 mm) |
| Turning Angle -From Center | 40 degrees |
| Turning Radius - Outside | 12.21 ft in (3721 mm) |
| Ground Clearance Under Shaft | 17.49 in (444 mm) |
| Bucket Reach - 7 Ft 0 (2.13m), 45° Dump | 43.39 in (1102 mm) |
| Bucket Reach - Fully Raised, 45° Dump | 30.16 in (766 mm) |
| Cab Height | 96.78 in (2458 mm) |
| Fuel Injection | High pressure common rail injection |
| Fuel Filter | Replaceable, full flow |
| Fan | Direct drive |
| Radiator Core Type | Staggered |
| Lubrication/Cooling Oil Pump | integral |
| Engine Oil | SAE 10W40, CJ-4 DIESEL, SAE 0W40, CJ-4 DIESEL |
| Pump | Deep sump plate cooler with pressurized under-piston nozzles |
| Pump Operating Angles -Side-To-Side | 35 degrees |
| Pump Operating Angles - Fore And Aft | 35 degrees |
| Oil Filtration | Replaceable, full flow |
| Engine Speed - Rated Speed, Full Load | 2500 rpm |
| Engine Speed- Low Idle | 950 rpm |
| Engine Speed - High Idle | 2500 rpm |
| Air Filter Type | Dry type element with warning restriction indicator |
| Horsepower - Gross | 57.7 hp (43 kw) |
| Horsepower -Net | 55 hp (41 kw) |
| Number Of Cylinders | 4 cylinders |
| Make / Displacement Liter | 3 |
| Engine Model | F5HFL463B*F001 |
| Engine Type | 4-stroke |
| Fuel Type | Diesel |
| Bore | 3.9 in (99 mm) |
| Stroke | 4.4 in (110 mm) |
| Pump (Steering/Implement) | Open-centered pressure/flow compensated. Fixed gear pump |
| Lift Cylinder(S) | two |
| Lift Cylinder-Bore Diameter | 2.8 in (70 mm) |
| Loader Control Valve | Open-center, Hydraulic Loader Control with single lever includes: Forward/Neutral/Reverse switch, Floating switch, Low/High Travel mode switch, Auxiliary Function Roller |
| Loader Auxiliary Steering | Hydraulic orbital center-pivot articulating w/on-demand oil flow |
| Lift Cylinder - Rod Diameter | 2.1 in (51 mm) |
| Filtration | 15-micron, full flow replaceable cartridges on return line |
| Flow At 2500 Rpm | 17.7 gal/hour (67 L/hour) |
| Lift Cylinder - Stroke | 28.7 in (728 mm) |
| Dump Cylinder - Bore Diameter | 3.3 in (83 mm) |
| Main Relief Pressure | 3335 psi (22994 kPa) |
| Dump Cylinder - Rod Diameter | 1.8 in (44 mm) |
| Dump Cylinder - Stroke | 19.4 in (492 mm) |
| Pump Type | Additional HF pump |
