Terex TXL300-1
Browse All Terex or Wheel Loader Models
Contents:
Bucket
| Dump Clearance At Max Raise | 9.51 ft in (2898 mm) |
| Bucket Capacity - Heaped | 3.67 yd3 (2.8 m3) |
| Bucket Width | 8.96 ft in (2730 mm) |
| Breakout Force | 40785 lb (181.43 kN) |
Dimensions
| Ground Clearance | 1.55 ft in (470 mm) |
| Length With Bucket On Ground | 26.02 ft in (7930 mm) |
| Height To Top Of Cab | 11.39 ft in (3470 mm) |
| Wheelbase | 10.5 ft in (3200 mm) |
| Hinge Pin - Max Height | 13.13 ft in (4000 mm) |
| Reach At Max Lift And Dump | 3.8 ft in (1157 mm) |
Engine
| Engine Make | 2253 |
| Engine Model | DE08TIS |
| Gross Power | 209 hp (155.9 kw) |
| Power Measured @ | 2100 rpm |
| Displacement | 492.5 cu in (8.1 L) |
| Aspiration | turbocharged |
Operational
| Operating Weight | 38140 lb (17300 kg) |
| Fuel Capacity | 85.1 gal (322 L) |
| Hydraulic System Fluid Capacity | 55.5 gal (210 L) |
| Engine Oil Fluid Capacity | 5.6 gal (21 L) |
| Cooling System Fluid Capacity | 13.3 gal (50 L) |
| Transmission Fluid Capacity | 12.7 gal (48 L) |
| Front Axle/Diff Fluid Capacity | 11.9 gal (45 L) |
| Rear Axle/Diff Fluid Capacity | 10.6 gal (40 L) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 65 amps |
| Rear Axle Oscillation | 24 degrees |
Transmission
| Transmission Type | full auto powershift |
| Number Of Forward Gears | 4 |
| Number Of Reverse Gears | 3 |
| Max Speed - Forward | 22.7 mph (36.5 km/h) |
| Max Speed - Reverse | 15.1 mph (24.3 km/h) |
Hydraulic System
| Relief Valve Setting | 2845 psi (19615.6 kPa) |
| Pump Flow Capacity | 73 gal/min (276.4 L/min) |
| Raise Time | 6 sec |
| Dump Time | 1.5 sec |
| Lower Time | 3.6 sec |
| Pump Type | sealed system with anticavitation and relief valves |
