Volvo BM 1254
Browse All Volvo BM or Wheel Loader Models
Contents:
Bucket
| Dump Clearance At Max Raise | 9.72 ft in (2960 mm) |
| Bucket Capacity - Heaped | 3.14 yd3 (2.4 m3) |
Dimensions
| Ground Clearance | 1.32 ft in (400 mm) |
| Length With Bucket On Ground | 21.17 ft in (6450 mm) |
| Width Over Tires | 8.47 ft in (2580 mm) |
| Height To Top Of Cab | 9.95 ft in (3030 mm) |
| Wheelbase | 8.47 ft in (2580 mm) |
| Hinge Pin - Max Height | 12.64 ft in (3850 mm) |
| Reach At Max Lift And Dump | 3.61 ft in (1100 mm) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2244 |
| Engine Model | D 100 B |
| Gross Power | 200 hp (149.2 kw) |
| Power Measured @ | 2200 rpm |
| Max Torque | 514.1 lb ft (697 Nm) |
| Torque Measured @ | 1400 rpm |
Operational
| Operating Weight | 30423.8 lb (13800 kg) |
| Static Tipping Weight | 18298.4 lb (8300 kg) |
| Turning Radius | 25 ft in (7600 mm) |
| Tire Size | 18X25/16SGEM |
Transmission
| Transmission Type | planetary |
| Number Of Forward Gears | 3 |
| Number Of Reverse Gears | 3 |
| Max Speed - Forward | 18.7 mph (30 km/h) |
| Max Speed - Reverse | 18.7 mph (30 km/h) |
Hydraulic System
| Relief Valve Setting | 2.2 psi (14.7 kPa) |
| Pump Flow Capacity | 7 gal/min (26.5 L/min) |
