Morris Maxim III 40'
Contents:
Frame Widths
| Transport Length | 31.5 ft in (9.6 m) |
| Transport Width | 19.85 ft in (6.05 m) |
| Transport Height | 17.33 ft in (5.28 m) |
| Inner Wing | 12.01 ft in (3.66 m) |
| Main Frame | 15.49 ft in (4.72 m) |
Base Size
| Base Width | 40 ft in (12.2 m) |
| Number Of Ranks | 4 |
| Rank To Rank Spacing | 23.5 in (59.7 cm) |
| Frame Depth | 78.4 in (199 cm) |
Working Width
| 7.5 In Spacing | 40 ft in (12.2 m) |
| 10 In Spacing | 40 ft in (12.2 m) |
| 12 In Spacing | 40 ft in (12.2 m) |
Number Of Shanks
| 7.5 In Spacing | 64 |
| 10 In Spacing | 48 |
| 12 In Spacing | 40 |
Weights
| 7.5 In Spacing | 26127 lb (11851 kg) |
| 10 In Spacing | 24323.6 lb (11033 kg) |
| 12 In Spacing | 23386.7 lb (10608 kg) |
Tires
| Main Frame Casters | (4) 12.5Lx15 FI load range f |
| Inner Wing Casters | (4) 12.5SLx15 |
| Rear Transport Wheels | (4) 12.5Lx15 FI load range f 8 bolt hub |
