Caterpillar 730C EJ
Browse All Caterpillar or Articulated Dump Truck Models
Contents:
Dump
| Rated Payload | 62000 lb (28122.73 kg) |
| Capacity - Heaped | 22.1 yd3 (16.9 m3) |
| Capacity - Struck | 17.7 yd3 (13.54 m3) |
Engine
| Engine Make | 2236 |
| Engine Model | C13 Acert |
| Gross Power | 375 hp (279.7 kw) |
| Net Power | 367 hp (273.7 kw) |
| Max Torque | 1164.7 lb ft (1579 Nm) |
| Torque Measured @ | 1200 rpm |
| Displacement | 763 cu in (12.6 L) |
| Bore | 5.2 in (130.1 mm) |
| Stroke | 6.2 in (157 mm) |
| Net Power - Sae J1349 | 367 hp (273.7 kw) |
| Gross Power - Sae J1995 | 375 hp (279.7 kw) |
| Engine Model | Cat C13 ACERT |
| Net Power - Iso 14396 | 370 hp (276 kw) |
| No Engine De-Rating Required Below | 12500 ft in (3810 m) |
| Peak Engine Torque Gross (Sae J1995) | 1579 lb ft (2140.9 Nm) |
| Peak Engine Torque Net (Iso 14396) | 1564 lb ft (2120.5 Nm) |
| Peak Engine Torque Speed | 1200 rpm |
| Engine Model - U.S. Epa Tier 4 Final/Eu Stage Iv | Cat C13 ACERT |
Operational
| Fuel Capacity | 108.8 gal (411.9 L) |
| Hydraulic System Fluid Capacity | 29 gal (109.8 L) |
| Cooling System Fluid Capacity | 21.9 gal (83 L) |
| Transmission Fluid Capacity | 9.2 gal (34.9 L) |
Transmission
| Number Of Forward Gears | 6 |
| Number Of Reverse Gears | 1 |
| Forward - 1 | 5 mph (8.1 km/h) |
| Forward - 2 | 9 mph (14.5 km/h) |
| Forward - 3 | 14 mph (22.6 km/h) |
| Forward - 4 | 21 mph (33.8 km/h) |
| Forward - 5 | 29 mph (46.7 km/h) |
| Forward - 6 | 34 mph (54.8 km/h) |
| Reverse - 1 | 6 mph (9.7 km/h) |
Steering
| Lock To Lock | 4.75 seconds @ 60 rpm |
Weights
| Center Axle - Empty | 12500 % |
| Front Axle - Empty | 34811 lb (15790.1 kg) |
| Rear Axle - Empty | 11773 lb (5340.2 kg) |
| Front Axle - Loaded | 36289 % |
| Center Axle - Loaded | 42758 % |
| Rear Axle - Loaded | 42031 lb (19065 kg) |
| Total Empty | 59084 lb (26800.1 kg) |
| Total Loaded | 61994 lb (28120.1 kg) |
Service Refill Capacities
| Cooling System | 21.9 gal (83 L) |
| Fuel Tank | 108.8 gal (411.9 L) |
| Engine Crankcase | 10.5 gal (39.8 L) |
| Transmission | 9.2 gal (34.9 L) |
| Hydraulic System | 29 gal (109.8 L) |
| Final Drives/Differential | 35.7 gal (135.2 L) |
| Output Transfer Gear Box | 6.3 gal (23.9 L) |
| Def Tank (Iso 2224-1) | 5.3 gal (20.1 L) |
Standards
| Cab - Fops | ISO 3449 Level II - 2005 |
| Cab - Rops | ISO 3471 - 2008 |
| Brakes | ISO 3450 - 2011 |
| Steering | ISO 5010 - 2007 |
Operating Weights
| Front Axle - Empty | 34811 lb (15790.1 kg) |
| Center Axle - Empty | 12500 lb (5670 kg) |
| Rear Axle - Empty | 11773 lb (5340.2 kg) |
| Total - Empty | 59084 lb (26800.1 kg) |
| Front Axle - Rated Load | 1478 lb (670.5 kg) |
| Center Axle - Rated Load | 30258 lb (13724.8 kg) |
| Rear Axle - Rated Load | 30258 lb (13724.8 kg) |
| Total - Rated Load | 61994 lb (28120.1 kg) |
| Front Axle - Loaded | 36289 lb (16460.5 kg) |
| Center Axle - Loaded | 42758 lb (19394.8 kg) |
| Rear Axle - Loaded | 42031 lb (19065 kg) |
| Total - Loaded | 121078 lb (54920.1 kg) |
Sound Levels
| Interior Cab | 76 dB(A) |
Turning Circle
| Note | Dimensions are for machines equipped with 750/65 tires. |
| Turning Dimensions - Steer Angle - Left/Right | 45 degrees |
| Turning Dimensions - Sae Turning Radius | 294 in (7467.6 mm) |
| Turning Dimensions - Clearance Radius | 318 in (8077.2 mm) |
| Turning Dimensions - Inside Radius | 148 in (3759.2 mm) |
| Turning Dimensions - Aisle Width | 214 in (5435.6 mm) |
Body Capacities
| Heaped (Sae 2:1) | 22.1 yd3 (16.9 m3) |
| Struck | 17.7 yd3 (13.6 m3) |
Body Plate
| Body Plate Type | High Strength Brinell HB450 Wear Resistant Steel |
Ejector Cycle Times
| Eject Time | 12 s |
| Retract Time | 15 s |
