Massey Ferguson MF 3640
Browse All Massey Ferguson or Combine Models
Contents:
Dimensions
| Overall Length | 26.84 ft in (8180 mm) |
| Width Over Tires | 10.31 ft in (3140 mm) |
| Height To Top Of Isomount Cab | 11.09 ft in (3380 mm) |
Engine
| Engine Make | 2351 |
| Engine Model | 1006-6 |
| Power | 123 hp (91.8 kw) |
| Power Measured @ | 2400 rpm |
| Displacement | 363.1 cu in (6 L) |
Operational
| Fuel Capacity | 87.2 gal (330 L) |
| Transmission Type | mechanical syncromesh |
| Number Of Gears | 3F 1R |
Feeding
| Conveyor Speed | 60 rpm |
Threshing
| Rotor Diameter | 22.1 in (560 mm) |
| Rotor Length | 42.6 in (1080 mm) |
| Rotor Speed - Low | 365 rpm |
| Rotor Speed - High | 1000 rpm |
| Concave Area | 883.6 in2 (0.6 m2) |
Separating
| Separator Type | 4 straw walkers, closed bottom |
| Separating Area | 7750.1 in2 (5 m2) |
Cleaning System
| Total Cleaning Area | 4805.1 in2 (3.1 m2) |
| Cleaning Fan Speed - Low | 974 rpm |
| Cleaning Fan Speed - High | 2075 rpm |
Grain Handling
| Grain Tank Capacity | 127.7 bu (4500 L) |
| Unloading Speed | 1.3 bu/sec (43 L/sec) |
