Michigan L160
Contents:
Dimensions
| Length With Blade On Ground | 27.3 ft in (8320 mm) |
| Ground Clearance | 1.78 ft in (540 mm) |
| Width Over Wheels | 10.77 ft in (3280 mm) |
| Height To Top Of Cab | 11.72 ft in (3570 mm) |
| Wheelbase | 11.65 ft in (3550 mm) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2244 |
| Engine Model | TD 102 G |
| Gross Power | 264 hp (196.9 kw) |
| Net Power | 252 hp (188 kw) |
| Power Measured @ | 2200 rpm |
| Displacement | 586 cu in (9.7 L) |
| Max Torque | 23.3 lb ft (31.6 Nm) |
| Torque Measured @ | 1400 rpm |
| Aspiration | turbocharged |
Operational
| Operating Weight | 60847.6 lb (27600 kg) |
| Fuel Capacity | 89.9 gal (340 L) |
| Hydraulic System Fluid Capacity | 84.6 gal (320 L) |
| Engine Oil Capacity | 7.7 gal (29 L) |
| Cooling System Fluid Capacity | 18.5 gal (70 L) |
| Transmission Fluid Capacity | 12.5 gal (47 L) |
| Tire Size | 26.5R25 |
| Static Tipping Load | 33885.1 lb (15370 kg) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 55 amps |
Transmission
| Transmission Type | Volvo BM HT 200 power shift |
| Number Of Forward Gears | 3 |
| Number Of Reverse Gears | 3 |
| Max Speed | 25.2 mph (40.5 km/h) |
Wheels
| Front Wheels Drum Width | 33.5 in (850 mm) |
| Front Wheels Drum Diameter | 55.2 in (1400 mm) |
| Rear Wheels Drum Width | 33.5 in (850 mm) |
| Rear Wheels Drum Diameter | 55.2 in (1400 mm) |
Blade
| Blade Capacity | 5.3 yd3 (4 m3) |
| Width | 11.2 ft in (3400 mm) |
