Komatsu D65S-7
Browse All Komatsu or Crawler Loader Models
Contents:
Dimensions
| Length With Bucket On Ground | 19 ft in (5790 mm) |
| Width To Outside Of Tracks | 7.73 ft in (2355 mm) |
| Height To Top Of Cab | 9.81 ft in (2990 mm) |
| Clearance At Full Height And Dump | 8.96 ft in (2730 mm) |
| Reach At Dump Height | 4.27 ft in (1300 mm) |
Undercarriage
| Track Gauge | 74.02 in (1880 mm) |
| Length Of Track On Ground | 8.65 ft in (2635 mm) |
| Number Of Track Rollers Per Side | 6 |
| Track Shoe Width | 18.12 in (460 mm) |
| Ground Pressure | 10.53 psi (72.61 kPa) |
Engine
| Engine Make | 2347 |
| Engine Model | NH220-CI |
| Net Power | 160 hp (119.4 kw) |
| Displacement | 743 cu in (12.2 L) |
Operational
| Operating Weight | 39683.3 lb (18000 kg) |
| Fuel Capacity | 74 gal (280 L) |
| Cooling System Fluid Capacity | 14.6 gal (55 L) |
| Static Tipping Load | 11300 lb (5125.6 kg) |
| Breakout Force - Std Bucket | 14020 lb (62.4 kN) |
| Bucket Capacity - Heaped | 2.4 yd3 (1.8 m3) |
| Max Speed | 6.1 mph (9.8 km/h) |
