Caterpillar 587T
Browse All Caterpillar or Crawler Pipe Layer Models
Contents:
Boom
| Max Lift Capacity | 202000 lb (91625.67 kg) |
Dimensions
| Overall Length | 18 ft in (5486 mm) |
| Overall Width | 13.25 ft in (4038 mm) |
| Width Over Tracks | 11.17 ft in (3403 mm) |
| Overall Height | 0.31 ft in (93 mm) |
| Length Of Track On Ground | 11.77 ft in (3587 mm) |
| Ground Clearance | 1.7 ft in (516 mm) |
| Shipping Height | 12.58 ft in (3834.39 mm) |
| Length | 18 ft in (5486.4 mm) |
| Shipping Width | 13.25 ft in (4038.6 mm) |
Undercarriage
| Track Gauge | 8.34 ft in (2540 mm) |
| Number Of Track Rollers Per Side | 1 |
| Shoe Size | 34.02 in (864 mm) |
| Number Of Shoes Per Side | 47 |
Engine
| Engine Make | 2236 |
| Engine Model | C15 ACERT |
| Net Power | 366.1 hp (273 kw) |
| Gross Power | 394.3 hp (294 kw) |
| Power Measured @ | 1800 rpm |
| Displacement | 927.6 cu in (15.2 L) |
| Bore | 5.4 in (137 mm) |
| Stroke | 6.8 in (172 mm) |
| Net Power - Iso 9249 | 366 hp (273 kw) |
| Engine Model | C15 |
| Flywheel Power | 366 hp (273 kw) |
Operational
| Fuel Capacity | 150.1 gal (568 L) |
| Cooling System Fluid Capacity | 20.4 gal (77 L) |
| Hydraulic System Fluid Capacity | 30.2 gal (114 L) |
| Final Drives Fluid Capacity | 3.4 gal (12.8 L) |
Transmission
| Number Of Forward Gears | 3 |
| Number Of Reverse Gears | 3 |
| Max Speed - Forward | 5.8 mph (9.4 km/h) |
| Max Speed - Reverse | 7.7 mph (12.4 km/h) |
Weights
| Operating Weight | 117000 lb (53070.4 kg) |
Hydraulic System
| Pump Type | Piston-type, Variable, two section |
| Relief Valve Pressure | 2498.3 psi (17225 kPa) |
| Pump Flow Capacity | 25.9 gal/min (98 L/min) |
Pipelaying Equipment
| Lift Capacity | 202000 lb (91625.7 kg) |
