Komatsu D275AX-5E0
Browse All Komatsu or Crawler Tractor Models
Contents:
Dimensions
| Height To Top Of Cab | 13.1 ft in (3990 mm) |
| Length Of Track On Ground | 11.42 ft in (3480 mm) |
| Ground Clearance | 1.67 ft in (507 mm) |
| Track Gauge | 7.42 ft in (2260 mm) |
| Length | 357.09 in (9070 mm) |
Undercarriage
| Number Of Shoes (Each Side) | 30 |
| Number Of Shoes Per Side | 39 |
| Number Of Track Rollers Per Side | 7 |
| Shoe Size | 24.02 in (610 mm) |
| Shoe Type | Komatsu K-Bogie |
| Suspension | Oscillating equaliser bar and pivot shaft |
| Track Rollerframe | Cylinder, high-tensile-strength steel construction |
| Ground Contact Area | 6580 in2 (4.25 m2) |
| Ground Pressure | 12.7 psi (87.57 kPa) |
| Grouser Height | 3.15 in (80 mm) |
| Number Of Carrier Rollers Per Side | 2 |
Steering System
| Minimum Turning Radius | 12.8 ft in (3.9 m) |
Engine
| Horsepower, Gross-Sae J1995 | 452 hp (337 kw) |
| Horsepower, Net-Iso 9249 | 449.3 hp (335 kw) |
| Horsepower, Net-Sae J1349 | 449.3 hp (335 kw) |
| Fan Drive Method | Hydraulic |
| Lubrication Method | Gear pump, force lubrication |
| Filter | Full flow |
| Number Of Cylinders | 6 |
| Engine Make | 2238 |
| Engine Model | SAA6D140E-5 |
| Engine Type | 4-cycle, water-ooled, direct injection |
| Governor | All speed, electronic |
| Power Measured @ | 2000 rpm |
| Displacement | 930.1 cu in (15.3 L) |
| Aspiration | Turbochanged |
| Bore | 5.6 in (140 mm) |
| Stroke | 6.5 in (165 mm) |
Driveline
| Maximum Speeds Fwd | 7 mph (11.2 km/h) |
| Maximum Speeds Rev | 9.3 mph (14.9 km/h) |
| Transmission | Torqflow |
| Number Of Speeds - Forward | 3 |
| Number Of Speeds - Reverse | 3 |
| Steering | Hydrostatic Steering System |
Capacities
| Transmission, Bevel Gear, And Steering System | 23.8 gal (90 L) |
| Fuel Tank | 222 gal (840 L) |
| Final Drive | 10.6 gal (40 L) |
| Engine Oil | 13.8 gal (52 L) |
| Coolant | 26.5 gal (100 L) |
Operational
| Blade Capacity | 18 yd3 (13.7 m3) |
| Blade Type | Semi-U (dual tilt) |
| Blade Length | 169.3 in (4300 mm) |
| Blade Height | 77.2 in (1960 mm) |
| Blade Cut Depth | 25.2 in (640 mm) |
| Ripper Type | Adjust |
| Ripper Depth | 35.5 in (900 mm) |
Transmission
| Transmission Type | Torqflow |
Weights
| Operating Weight | 114688.9 lb (52022 kg) |
| Ripper Weight | 9837.1 lb (4462 kg) |
| Blade Weight | 16667 lb (7560 kg) |
Hydraulic System
| Hydraulic System Type | Closed-center Load Sensing System (CLSS) |
