Case IH MRX 690 5-Shank
Contents:
Dimensions
| Overall Length | 30.08 in (9168.39 mm) |
| Transport Width | 15.75 ft in (4800.61 mm) |
| Main Frame Tires | 12.5Lx15 8 ply |
| Max Weight | 9680 lb (4390.78 kg) |
| Working Width Spacing #1 Min | 12.5 ft in (3810 mm) |
Disc System
| Spacing #1 | 12 in (304.8 mm) |
| Blade Diameter | 24 in (609.6 mm) |
| Depth Control | mechanical |
| Max Operating Depth | 5 in (127 mm) |
Shanks
| Number Of Main Shanks | 5 |
| Shank Spacing | 30 in (762 mm) |
| Shank Working Depth | 14 in (355.6 mm) |
| Shank Trip Force | 1800 lb (816.5 kg) |
