BT DT25P
Contents:
Dimensions
| Length To Fork Face | 8.67 ft in (2640 mm) |
| Overall Width | 3.78 ft in (1150 mm) |
| Overall Height - Mast Lowered | 6.55 ft in (1995 mm) |
| Wheelbase | 5.42 ft in (1650 mm) |
| Ground Clearance | 4.14 in (105 mm) |
| Height To Top Of Overhead Guard | 6.93 ft in (2110 mm) |
| Max Fork Height | 9.85 ft in (3000 mm) |
| Turning Radius | 7.49 ft in (2280 mm) |
Mast
| Mast Tip Forward | 6 degrees |
| Mast Tip Rear | 11 degrees |
| Lower Speed | 98.43 ft/min (30 m/min) |
| Load Capacity | 5511.56 lb (2500 kg) |
| Load Center | 19.69 in (500 mm) |
| Lift Speed | 137.8 ft/min (42 m/min) |
Engine
| Engine Make | 2304 |
| Engine Model | 3Z |
| Power | 56.4 hp (42 kw) |
| Torque | 147.6 lb ft (200 Nm) |
| Power Measured @ | 2200 rpm |
| Displacement | 211.7 cu in (3.5 L) |
| Torque Measured @ | 1600 rpm |
| Fuel Type | diesel |
Operational
| Operating Weight | 8046.9 lb (3650 kg) |
| Tire Type | pneumatic front 7.00-12.12PR rear 6.00-9-10PR |
| Number Of Front Wheels | 2 |
| Number Of Rear Wheels | 2 |
| Max Speed | 12.2 mph (19.5 km/h) |
