BT GT25
Contents:
Dimensions
| Length To Fork Face | 8.67 ft in (2640 mm) |
| Overall Width | 3.78 ft in (1150 mm) |
| Overall Height - Mast Lowered | 6.55 ft in (1995 mm) |
| Wheelbase | 5.42 ft in (1650 mm) |
| Ground Clearance | 4.14 in (105 mm) |
| Height To Top Of Overhead Guard | 6.93 ft in (2110 mm) |
| Max Fork Height | 9.85 ft in (3000 mm) |
| Turning Radius | 7.49 ft in (2280 mm) |
Mast
| Mast Tip Forward | 6 degrees |
| Mast Tip Rear | 11 degrees |
| Lower Speed | 98.43 ft/min (30 m/min) |
| Load Capacity | 5511.56 lb (2500 kg) |
| Load Center | 19.69 in (500 mm) |
| Lift Speed | 125.99 ft/min (38.4 m/min) |
Engine
| Engine Make | 2304 |
| Engine Model | 4Y |
| Power | 51 hp (38 kw) |
| Torque | 118.1 lb ft (160 Nm) |
| Power Measured @ | 2570 rpm |
| Displacement | 136.6 cu in (2.3 L) |
| Torque Measured @ | 2100 rpm |
| Fuel Type | LPG |
Operational
| Operating Weight | 7848.5 lb (3560 kg) |
| Tire Type | pneumatic front 7.00-12.12PR rear 6.00-9-10PR |
| Number Of Front Wheels | 2 |
| Number Of Rear Wheels | 2 |
| Max Speed | 11.2 mph (18 km/h) |
