Crown RD 5275S
Contents:
Dimensions
| Length To Fork Face | 5.01 ft in (1525.53 mm) |
| Overall Width | 4 ft in (1219.2 mm) |
| Overall Height - Mast Lowered | 7.42 ft in (2260.62 mm) |
| Wheelbase | 5.12 ft in (1557.53 mm) |
| Ground Clearance | 2 in (50.8 mm) |
| Height To Top Of Overhead Guard | 7.42 ft in (2260.62 mm) |
| Max Fork Height | 16.5 ft in (5029.2 mm) |
Mast
| Mast Tip Forward | 3 degrees |
| Mast Tip Rear | 4 degrees |
| Load Center | 24 in (609.6 mm) |
| Max Fork Spread | 30 in (762 mm) |
| Load Capacity | 3000 lb (1360.78 kg) |
| Lift Speed | 93 ft/min (93 -) |
| Lower Speed | 90 ft/min (90 -) |
Engine
| Fuel Type | Electric 36V |
Operational
| Operating Weight | 8329 lb (3778 kg) |
| Tire Type | Poly |
| Number Of Front Wheels | 4 |
| Number Of Rear Wheels | 2 |
| Max Speed | 7.5 mph (12.1 km/h) |
