Hyster H60XT
Contents:
Dimensions
| Length To Fork Face | 8.87 ft in (2701 mm) |
| Overall Width | 3.91 ft in (1191 mm) |
| Overall Height - Mast Lowered | 7.37 ft in (2245 mm) |
| Wheelbase | 5.58 ft in (1700 mm) |
| Ground Clearance | 8.27 in (210 mm) |
| Height To Top Of Overhead Guard | 7.39 ft in (2250 mm) |
| Max Fork Height | 10.53 ft in (3209 mm) |
| Gradeability | 23.5 % |
| Right Angle Stack | 9.2 ft in (2802 mm) |
| Turning Radius | 7.63 ft in (2324 mm) |
Mast
| Mast Tip Forward | 6 degrees |
| Mast Tip Rear | 6 degrees |
| Lower Speed | 114 ft/min (34.75 m/min) |
| Load Center | 24.02 in (610 mm) |
| Load Capacity | 6000 lb (2721.56 kg) |
| Lift Speed | 112 ft/min (34.14 m/min) |
Engine
| Number Of Cylinders | 4 |
| Engine Model | PSI 2.4L |
| Power | 62 hp (46.3 kw) |
| Torque | 124 lb ft (168.2 Nm) |
| Power Measured @ | 2700 rpm |
| Displacement | 143 cu in (2.4 L) |
| Torque Measured @ | 1600 rpm |
| Fuel Type | LPG |
Operational
| Operating Weight | 10300 lb (4672.1 kg) |
| Tire Type | Pneumatic |
| Number Of Front Wheels | 2 |
| Number Of Rear Wheels | 2 |
| Max Speed | 12.4 mph (20 km/h) |
| Drawbar Pull | 4438 lb (2013.1 kg) |
| Fuel Capacity | 18.2 gal (68.9 L) |
| Front Tire Size | 28 x 9 - 15 |
| Rear Tire Size | 6.50 x 10 |
| Hydraulic System Relief Valve Pressure | 2550 psi (17581.7 kPa) |
| Hydraulic Tank | 11.1 gal (42.1 L) |
| Axle Load - Front | 4207 lb (1908.3 kg) |
| Axle Load - Rear | 6089 lb (2762 kg) |
Brakes
| Service Brake | Foot/Hydraulic |
| Parking Brake | Hand/Mechanical |
