Nissan PF55
Contents:
Dimensions
| Length To Fork Face | 8.57 ft in (2610 mm) |
| Overall Width | 3.35 ft in (1020 mm) |
| Overall Height - Mast Lowered | 7.14 ft in (2175 mm) |
| Wheelbase | 5.32 ft in (1620 mm) |
| Ground Clearance | 5.71 in (145 mm) |
| Height To Top Of Overhead Guard | 7.06 ft in (2150 mm) |
| Max Fork Height | 10.83 ft in (3300 mm) |
| Counterweight Clearance | 3.61 ft in (1100 mm) |
| Fork Length | 42.13 in (1070 mm) |
| Fork Thickness | 1.58 in (40 mm) |
| Fork Width | 3.94 in (100 mm) |
| Gradeability | 30 % |
| Right Angle Stack | 8.9 ft in (2710 mm) |
| Turning Radius | 7.35 ft in (2240 mm) |
Mast
| Lift Speed | 104.3 ft/min (31.8 m/min) |
| Load Center | 24 in (609.6 mm) |
| Load Capacity | 5500 lb (2494.76 kg) |
Engine
| Engine Make | Nisaan K25 |
| Power | 62.9 hp (47 kw) |
| Torque | 138.7 lb ft (188 Nm) |
| Power Measured @ | 2700 rpm |
| Displacement | 151.8 cu in (2.5 L) |
| Torque Measured @ | 1600 rpm |
Operational
| Operating Weight | 8825 lb (4003 kg) |
| Tire Type | pneumatic |
| Number Of Front Wheels | 2 |
| Number Of Rear Wheels | 2 |
| Max Speed | 12.1 mph (19.5 km/h) |
